Various Indicator Plates and Warning Plates
The indicator plate for fuel No. is
located inside the cap of the oil
. filler
7
1、Warnin g pla te for power-assisted steerin g oil .
2、Warnin g pla te for oil and coola nt fil li ng.
3、Warnin g pla te for A/C refrig erant.
4、Warnin g pla te for gla ss cleaning solu tio n.
5、Warnin g plate for engine coola nt.
8
Notes for air bag are located on
the front passenger sun visor.
The indicator plate for tire pressure is
located at the lowe r side of the left
front door lock.
1
4
2
3
5
LF481 Q3
1
2 3
4
5
TRITE C1.6L
Instru ction Manual of Lifa n Sedan
LIFAN
Instru ction Manual of Lifa n Sedan
Instru ction Manual of Lifa n Sedan
LIFAN
620 620
Chongqing Lifan Passenger Vehicle Co. , Ltd.
Chongqing Lifan Passenger Vehicle Co. , Ltd.
