Technical Parameter & Vehicle Identification (LF 620 Complete Car)
……Technical Parameter
Vehic le Identif ication
Various Indicator Pla tes and Warnin g Pla tes
……… ………… ………… ………… ………………………………4
……… ………… ………… ………… ……………………………………6
………………………………………………7
3
Technical Parameter
Product Model
LF7162 LF7162A LF7162B LF7162C LF7162D LF7162E
L (mm)
4550
W (mm)
1705
Outline Dimension
H (mm)
1495
Wheel Base (mm)
2605
Front (mm)
1470
Track
Rear (mm)
1460
Vehicle Weight (kg)
1150
Vehicle Weight with Load (kg)
1555
Wheel Specification
195/60R15
Approach Angle (°)
≥19°
Departure Angle (°)
≥17°
Front Suspension (mm)
940
Rear Suspension (mm)
1005
Passengers
5
4
Instru ction Manual of Lifan Sedan
LIFAN
Instru ction Manual of Lifan Sedan
Instru ction Manual of Lifan Sedan
LIFAN
620620 620
Chongqing Lifan Passenger Vehicle Co. , Ltd.
Chongqing Lifan Passenger Vehicle Co. , Ltd.
