SOLID STATE LOGIC Alpha Link MX 4-16 IO Bundle [11/52] Un pack
![SOLID STATE LOGIC Alpha Link MX 4-16 IO Bundle [11/52] Un pack](/views2/1989593/page11/bgb.png)
5
EN
DE
ES
FR
IT
JP
Un-pack
Your XLogic Alpha-Link MX box should contain the following:
5A
XLogic Alpha-Link MX
Installation and User Guide
Hinweise zur Installation
Guía de Instalación
Guide d’Installation
Installazione Prodotto
インストール・ガイド
XLogic Alpha-Link. This is SSL.
EN
DE
ES
FR
IT
JP
JP
(marked ‘PSE’)
oror
The XLogic Alpha-Link MX Unit
(Alpha-Link MX 16-4 shown)
Multiple power cords may be supplied.
Please dispose of unused cords safely.
or
US
(marked ‘UL’)
EU
Installation and User Guide
(this document)
Power Cord(s)
