SOLID STATE LOGIC Alpha Link MX 4-16 IO Bundle [7/52] Introduction
![SOLID STATE LOGIC Alpha Link MX 4-16 IO Bundle [7/52] Introduction](/views2/1989593/page7/bg7.png)
1
EN
DE
ES
FR
IT
JP
Introduction
Congratulations on your purchase of this Solid State Logic Alpha-Link MX audio I/O unit. Please be assured that it
will provide you with many years of reliable service while delivering the pristine audio quality you expect from any
Solid State Logic product.
The Alpha-Link MX is a stylishly designed, 1U-high rack-mountable unit providing MADI to multi-channel audio
conversion for Studio, Live and Broadcast Applications with an incredible price/performance ratio. Alpha-Link MX is
configurable to suit all common professional analogue interface levels.
The unit offers simple front panel controls for configuration, mode indicator LEDs and a meter section for the analogue
inputs and outputs. Multiple units may be connected to a single MADI stream to increase the analogue I/O count.
IMPORTANT
Please register your Alpha-Link MX unit on our website. This will ensure that you receive notification of future
updates and other important information, and that your guarantee is registered. Registration will also make
you eligible for technical support.
The Solid State Logic home page is at:
www.solidstatelogic.com
From there you can access our Support page, which includes links to the Product Registration and Download
pages. You can also visit the Frequently Asked Questions (FAQ) area for any questions you might have or to
contact our Technical Support staff.
