25
EN
DE
ES
FR
IT
JP
Conectar
Para las clavijas del conector, consulte la página 3.
Interruptor de la unidad ID (conexión en bucle MADI)
Posiciones Funciones
1ª unidad en la cadena MADI
(por defecto)
2ª unidad en la cadena MADI
3ª unidad en la cadena MADI
4ª unidad en la cadena MADI
16 entradas analógicos
4 salidas
analógicos
16 salidas analógicos
4 entradas
analógicos
Alpha-Link
MX 16-4
Alpha-Link
MX 4-16
USB
(sólo para la actualización del firmware)
MADI I/O
Wordclock entrada,
wordclock salida
Suministro de corriente alterna
