AUDIX f6 [2/2] Architect and engineer specifications

AUDIX f6 [2/2] Architect and engineer specifications
f6
Hi
Lo
FREQUENCY RESPONSE
POLAR PATTERNS
ARCHITECT AND ENGINEER SPECIFICATIONS
The microphone shall be of the dynamic type operating on the moving
coil principle and the capsule shall be LM Type A. The polar pattern of
the microphone shall be hypercardioid. The nominal output impedance
shall be 580 ohms at 1 kHz. The microphone shall have a sensitivity of
1.2 mV / Pa at 1 kHz and shall handle a sound pressure level of ≥140
dB. The microphone body shall be cast of zinc alloy metal and the grill
cap shall be steel wire mesh. The overall dimensions shall be 21 mm in
diameter at the base, 58 mm in diameter at the widest point and 121
mm in length.
OPERATION AND MAINTENANCE
The f6 is a low impedance microphone and should be plugged into
a “mic level” of your console, mixer, or recording device. Please note
that your microphone does not require phantom power and will
not be affected in any way by phantom power should it be running
simultaneously while the microphone is in operation. Avoid plugging
or unplugging the microphone from the PA system unless the channel
is muted or the volume of the system turned down. Failure to do so
may result in a loud “popping” noise which could seriously damage the
speakers in the PA system.
The f6 is manufactured to exacting specs with roadworthy construction.
However, the capsule is highly sensitive and should be handled with
care. Avoid extreme temperatures and be sure to store your microphone
in the pouch provided when not in use. Moisture of any kind can
adversely effect the sound and performance of your microphone.
USER TIPS
The f6 is designed with low output in order to compensate for instru-
ments having very high sound pressure levels.
Kick drums: For kick drums, as a general rule, start with the mic po-
sitioned centered inside the middle of the drum pointed towards the
beater. For more attack, and less bass boom, move the mic closer to the
beater. For less attack and more bass, move the mic further away from
the beater. For kick drums without hole in front head, place the f6 a few
inches from the head for a large dynamic sound.
Toms: For toms, position the mic 2 inches from the head and point to-
wards the center of the drum.
Bass cabinets: For bass cabinets, position the mic 90 degrees to the
grill cloth and 1-2 inches inside the edge of the speaker.
Further miking techniques may be found at www.audixusa.com.
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
www.audixusa.com
503.682.6933 Fax: 503.682.7114
Audix Corporation 9400 SW Barber St. Wilsonville, OR 97070
ver 2.0 06-15
SPECIFICATIONS
Transducer Type
Dynamic
Frequency Response
40 Hz - 16 kHz
Polar Pattern
Hypercardioid
Output Impedance
580 ohms
Sensitivity
1.2 mV / Pa @ 1k
Capsule Technology
LM Type A
Off-Axis Rejection
>23 dB
Maximum SPL
≥140 dB
Power Requirements
None
Connector
3-pin XLRm
Polarity
Positive pressure on diaphragm
produces positive voltage on
pin 2 relative to pin 3 of output
XLR connector
Materials / Finish
Zinc Alloy / Black Finish
Weight
311 g / 11 oz
Length
121 mm / 4.76 in
SERVICE AND WARRANTY
This microphone is under warranty for a period of 3 years to be free of defects in material and workmanship. In the event of a product failure due to materials or workmanship, Audix will
repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes any causes other
than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions. No Implied
Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a particular purpose are hereby excluded. The liability of Audix, if any,
for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages
of any kind. Should your microphone fail in any way, please contact the Audix Service department at 503.682.6933. A Return Authorization is required before returning any product.
OTHER THAN THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS, THE USE OF THE PRODUCTS, THE PERFORMANCE OF THE PRODUCTS. AUDIX
SHALL NOT BE LIABLE FOR SPECIAL INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THE SALE, USE, STORAGE OR DISPOSAL OF THE PRODUCTS, AUDIX’S
SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT. NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
PRODUCT REGISTRATION
Please register your product online at www.audixusa.com/docs_12/about/product_registration.shtml.
DIMENSIONS (mm)
