American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 10American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 9

Comscan LED System Menu

System Menu: When making adjustments you can press

ENTER to conrm your setup or you can wait 8 seconds for

automatic setup. To exit without making any adjustments

press the MENU button.

ADDR - DMX Address Setting.

1. Tap the either the MENU, UP, or DOWN buttons until “ADDR”

is displayed, press ENTER.

2. The current address will now be displayed and ashing.

Press the UP or DOWN buttons to nd your desired address.

Press ENTER to set your desired DMX address.

SLMD - This will let you set unit as a master or slave in a

master/slave conguration.

1. Tap the MENU button until “SLMD” is displayed, press

ENTER. Either “SL 1” or “SL 2” will be displayed.

2. Tap the UP or DOWN buttons until your desired setting is

displayed, press ENTER to conm.

NOTE: In a Master/Slave conguration you can set one xture

to Master and then set the next xture to “SL 2”, the xtures will

now have contrast movement to each other.

SHND: SH 0 - 12 - Show modes 0-12 (Factory programs).

You can run show mode with sound active mode off or on.

1. Tap the MENU button until “SHND” is displayed, press

ENTER.

2. “Sh X” will now be displayed, “X” representing a number

between 0-12. Programs 1-12 are factory programs, while “Sh

0” is random mode. Press the UP or DOWN buttons to nd your

desired show and press the ENTER, then press and hold the

MENU button for at least 3 seconds to conrm.

SOUN - Sound Active mode.

1. Tap the MENU button until “SOUN” is displayed, press

ENTER.

2. The display will show either “ON” or “OFF”. Press the UP or

DOWN buttons to select “ON” to activate sound active mode, or

“OFF” to deactivate sound active mode.

3. Press ENTER to conrm.

BLND - Blackout or Stand by mode.

1. Tap the MENU button until “BLND” is displayed, press

ENTER. Either Yes or No will be displayed.

2. To activate Blackout tap the UP or DOWN buttons until “Yes”

is displayed, press ENTER to conm. The xture will now be in

Blackout mode. To deactivate Blackout mode, select “No” and

press Enter.

LED - With this function you can have the LED display

turn off after 10 seconds.

1. Tap the MENU button until “LED” is displayed, press ENTER.

2. The display will show either “ON” or “OFF”. Press the UP or

DOWN buttons to select “ON” to keep the LED display on at

all times, or “OFF” to switch to have the LED display switch off

after 10 seconds.

3. Press ENTER to conrm.

DISP - This function will reverse the display 180º.

1. Tap the MENU button until “DISP” is displayed, press ENTER.

2. Press ENTER to “ip” the display. Press ENTER to “ip” it

again. Press ENTER when you have made your desired setup.

Comscan LED System Menu
