AMERICAN DJ Comscan LED System [8/10] Channel value function

Comscan LED Cleaning

Comscan LED Trouble Shooting

Trouble Shooting: Listed below are a few common problems that

you may encounter, with solutions.

No light output from the unit;

1. Be sure you have connected your unit into a standard 120v wall

outlet.

2. Be sure the external fuse has not blown. The fuse is located on

the rear panel of the unit.

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the

internal and external optical lenses and mirror should be carried out

periodically to optimize light output. Cleaning frequency depends on

the environment in which the fixture operates (I.e. smoke, fog residue,

dust, dew). In heavy club use we recommend cleaning on a monthly

basis. Periodic cleaning will ensure longevity, and crisp output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

2. Use a brush to wipe down the cooling vents and fan grill.

3. Clean the external optics and mirror with glass cleaner and a soft

Locate and remove the unit’s power cord. Once the cord has been

removed located the fuse holder located inside the power socket.

Insert a flat-head screw driver into the power socket and gently pry

out the fuse holder. Remove the bad fuse and replace with a new one.

The fuse holder has a built-in socket for a spare fuse be sure not to

confuse the spare fuse with active fuse.

American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 16American DJ® - www.americandj.com - Comscan LED Instruction Manual Page 15

Channel Value Function

1 0 - 255 PAN

16 - 131 STROBING SLOW - FAST

132 - 139 OPEN

140 - 181 SLOW OPEN - FAST CLOSE

182 - 189 OPEN

190 - 231 FAST OPEN - SLOW CLOSE

232 - 239 OPEN

240 - 247 RANDOM STROBE

248 - 255 OPEN

4 GOBO WHEEL

0 - 7 OPEN

50 - 56 GOBO 7

57 - 63 GOBO 8

64 - 71 OPEN SHAKE

72 - 78 GOBO 1 SHAKE

79 - 85 GOBO 2 SHAKE

86 - 92 GOBO 3 SHAKE

93 - 99 GOBO 4 SHAKE

100 - 106 GOBO 5 SHAKE

107 - 113 GOBO 6 SHAKE

114 - 120 GOBO 7 SHAKE
