©American Audio® - www.americanaudio.us - PXW 15P - Instruction Manual Page 10

Model: American Audio® PXW 15P - Professional Powered Subwoofer

Component: 15” Woofer (4 Ohm)

Dimensions: 23.7” x 17.2” x 23.5” / 603mm x 436mm x 597mm

Weight: 88 Lbs. / 40 kgs

Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)

Operational humidity: 25 to 85% RH (non-condensation)

Storage temperature: -20 to 60˚C (4 to 140˚F)

Frequency Response: (-3dB) : 45Hz ~ 120Hz

Frequency Range: (-10dB) : 35Hz ~ 120Hz

Maximum SPL @ 1m: 126dB

Peak Output @ 1m: 129dB

Crossover Frequency: 120Hz (12dB/octave)

Input Type: Balanced Differential

Input Impedence: 50k

Input Protection: Level Protected

Thermal Protection: Input Stage Muting, Auto-Reset

Low-Frequency Tranducer Diameter: 15” (380mm)

Voice Coil Diameter: 4” (100mm)

Low-Frequency Power Amplifier: Rated Power* 500 Watts Continuous, 700 Watts Peak

Rated THD: < 0.03%

Cooling: Passive-Heatsink with Speed Sensitive Electric Fan

NOTES:

The specifications are subject to change to any improvement by negotiations in advance.

The parts are subject to change to any improvement within the range of the specifications.

PXW 15P™ Technical Specifications
