©American Audio® - www.americanaudio.us - PXW 15P - Instruction Manual Page 7

PXW 15P Controls and Features

active speaker or power amp.

7. PHASE SWITCH – The PHASE SWITCH reverses the polarity of the subwoofer. This switch

depends on the placement of the subwoofer relative to the speakers. Experiment with the

switch and postions of the subwoofer and speakers to find the best sound.

8. FULL RANGE XLR INPUT – These connections are designed to accept a line input signal from

a mixer or other line level device with a balanced output jack. Use a balanced cable when the

signal cable length exceeds 15 feet, this will reduce excessive signal loss. Be sure to connect

only line level input devices such as mixers to these inputs.

9. THRU (FULL RANGE OUTPUT) – These outputs are used to send the signal from the FULL RANGE

INPUTS to another device.
