ADJ Products, LLC - www.adj.com - Vizi Q Wash7 Instruction Manual Page 23ADJ Products, LLC - www.adj.com - Vizi Q Wash7 Instruction Manual Page 22
Vizi Q Wash7 System Menu
Set Address
A001~AXXX
User Mode
Standard
Basic
Extend
User A
User B
User C
Edit A
Edit B
Edit C
Max Channel
PAN
:
Status
Remote Add
No DMX Mode
Pan Invert
Tilt Invert
Pan Degree
Feedback
Move.Spd
Stand By
ON/OFF
Blackout/ Hold/Auto
ON/OFF
ON/OFF
630/ 540
ON/OFF
Speed 1 ~ 4
OFF, 01M~99M，15M
Fixture ID
Service PIN
RDM PID
Password=xxx
xxxxxx
Fan Set
Head Fan Auto
High
Low
LCD.Set
Backlight
Flip Display
Key Lock
DispFlash
02~60m <05m>
ON/OFF
ON/OFF
ON/OFF
Dim Curve
Standard
Stage
TV
Architectural
Theatre
Temp. C/F
Celsius
Fahrenheit
Init.Eect
PAN =XXX
Disp.Set
Chan.Value
Slave Set
Auto.Pro
PAN……
Slave1,Slave2,Slave3
Master / Alone
DFSE
ON/OFF
Time.Info
Current
Total Time
Last Clear
Timer PIN
Clear Last
Check the current running
time(H)
Total time(Hours)
Clear the running time of
xture(Hours)
（Password=050）
ON/OFF
Temp. Info
Head Temp.
Error. Info
Pan,Tilt …..
Model. Info
VIZI Q WASH7
Software.V
1U01 V1.01 ……
2U01 V1.01 ……
3U01 V1.01 ……
3U02 V1.01 ……
Reset.M
Pan&Tilt
Test.Chan
PAN ……
Panel.Ctrl.
PAN =XXX
:
Calibrate
- Password-
PAN
:
Select .Pro
Pro. Part 1 = Program 1 ~ 9 Program 1
Pro. Part 2 = Program 1 ~ 9 Program 2
Pro. Part 3 = Program 1 ~ 9 Program 3
Information
Test
Function
User Mode
Receive
Program
Edit. Pro
Program 1
:
Program 9
Program Test
Step 01=SCxxx
Step 64=SCxxx
Edit.Sce
Edit Scene 001
~ Edit Scene 250
Pan,Tilt, ……
Fade Time
Secne Time
Input By Outside
Sce.Input
XX~XX video scenes automatically
Password =050 ”
Wireless OFF...CH00~14
Vizi Q Wash7 Color Macro Chart
Color No. DMX
VAULE
RGBW COLOR INTENSITY Color No. DMX
VAULE
RGBW COLOR INTENSITY
RED GREEN BLUE WHITE RED GREEN BLUE WHITE
OFF 0 0 0 0 0 Color33 129-132 255 206 143 0
Color1 1-4 80 255 234 80 Color34 133-136 254 177 153 0
Color2 5-8 80 255 164 80 Color35 137-140 254 192 138 0
Color3 9-12 77 255 112 77 Color36 141-144 254 165 98 0
Color4 13-16 117 255 83 83 Color37 145-148 254 121 0 0
Color5 17-20 160 255 77 77 Color38 149-152 176 17 0 0
Color6 21-24 223 255 83 83 Color39 153-156 96 0 11 0
Color7 25-28 255 243 77 77 Color40 157-160 234 139 171 0
Color8 29-32 255 200 74 74 Color41 161-164 224 5 97 0
Color9 33-36 255 166 77 77 Color42 165-168 175 77 173 0
Color10 37-40 255 125 74 74 Color43 169-172 119 130 199 0
Color11 41-44 255 97 77 74 Color44 173-176 147 164 212 0
Color12 45-48 255 71 77 71 Color45 177-180 88 2 163 0
Color13 49-52 255 83 134 83 Color46 181-184 0 38 86 0
Color14 53-56 255 93 182 93 Color47 185-188 0 142 208 0
Color15 57-60 255 96 236 96 Color48 189-192 52 148 209 0
Color16 61-64 238 93 255 93 Color49 193-196 1 134 201 0
Color17 65-68 196 87 255 87 Color50 197-200 0 145 212 0
Color18 69-72 150 90 255 90 Color51 201-204 0 121 192 0
Color19 73-76 100 77 255 77 Color52 205-208 0 129 184 0
Color20 77-80 77 100 255 77 Color53 209-212 0 83 115 0
Color21 81-84 67 148 255 67 Color54 213-216 0 97 166 0
Color22 85-88 77 195 255 77 Color55 217-220 1 100 167 0
Color23 89-92 77 234 255 77 Color56 221-224 0 40 86 0
Color24 93-96 158 255 144 144 Color57 225-228 209 219 182 0
Color25 97-100 255 251 153 153 Color58 229-232 42 165 85 0
Color26 101-104 255 175 147 147 Color59 233-236 0 46 35 0
Color27 105-108 255 138 186 138 Color60 237-240 8 107 222 0
Color28 109-112 255 147 251 147 Color61 241-244 107 156 231 0
Color29 113-116 151 138 255 138 Color62 245-248 165 198 247 0
Color30 117-120 99 0 255 100 Color63 249-252 0 0 189 0
Color31 121-124 138 169 255 138 Color64 253-255 255 255 255 0
Color32 125-128 255 255 255 255
