AMERICAN DJ Vizi QWash7 [21/24] Master slave cofiguration auto program

ADJ Products, LLC - www.adj.com - Vizi Q Wash7 Instruction Manual Page 40 ADJ Products, LLC - www.adj.com - Vizi Q Wash7 Instruction Manual Page 41

Stand-Alone (Auto Program): This mode allows a single unit to

run through a built-in program.

AUTO PROGRAM:

1. Access the main menu, and press the UP or DOWN buttons so

that “Function” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Disp. Set” is displayed,

and press ENTER.

3. Press the UP or DOWN buttons until “Auto. Pro” is displayed,

the others will react to the controlling units programs. Any unit can act

as a Master or as a Slave.

1. Using standard XLR cables, daisy chain your units together viathe

XLR connector on the rear of the units. Remember the Male XLR

connector is the input and the Female XLR connector is the

output. The rst unit in the chain (master) will use the female XLR

connector only - The last unit in the chain will use the male XLR

connector only. For longer cable runs we suggest a terminator at

the last fixture.

2. On your “Master” unit, access the main menu, and press the UP

5. Either “Master” or “Alone” will be displayed. Using the UP or

DOWN buttons select “Master” and press ENTER.

6. For your “Slave” units, access the main menu, and press the UP

or DOWN buttons so that “Function” is highlighted, then

press ENTER.

7. Press the UP or DOWN buttons until “Disp. Set” is displayed,

and press ENTER.

Vizi Q Wash7 Operation Vizi Q Wash7 Operation

8. Press the UP or DOWN buttons until “Slave Set” is displayed,

and press ENTER.

of XLR cables. Your DMX controller must be connected to a ADJ WiFly

TransCeiver to use this function. You are able to communicate up to 2500

feet/760 meters (open line of sight).

1. Follow the instructions on page 33 to activate WiFly and set the

Wireless address. The address must match the address set on the WiFly

Transceiver.

2. After you have set the WiFly address, follow the DMX instructions on

page 24 to select your desired DMX Channel mode and set your DMX

address.

3. Apply power to the ADJ WiFly Transceiver. The fixture must be set up

Wireless address. The address must match the address set on the WiFly

Transceiver.

2. After you have set the WiFly address, select your master unit and set

your desired operating mode.

3. For the Slave units, put the unit in Slave mode. See page 40 Master-

Slave configuration when setting the unit as a Slave.

NOTE: If they do not sync up master-slave, switch the Master fixtures

WiFly off then on again.

Vizi Q Wash7 WiFly Master-Slave Set Up
