ADJ Products, LLC - www.adj.com - Vizi Q Wash7 Instruction Manual Page 31
ADJ Products, LLC - www.adj.com - Vizi Q Wash7 Instruction Manual Page 30
Vizi Q Wash7 System Menu
tons to toggle between.
5. Press ENTER to conrm your selection or press MODE to exit.
Key Lock - With this function activated the buttons will lock autom-
matically after 15 seconds.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “LCD.Set” is displayed,
press ENTER.
3. Press LEFT or RIGHT buttons, until “Key Lock” is displayed, and
press ENTER.
4. Either “O” or “On” will be displayed, use the LEFT or RIGHT but-
tons to toggle between.
5. Press ENTER to conrm your selection or press MODE to exit.
DispFlash - With this function active, the display will ash when the
DMX signal is lost.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “LCD.Set” is displayed,
press ENTER.
3. Press LEFT or RIGHT buttons, until “DispFlash” is displayed, and
press ENTER.
4. Either “O” or “On” will be displayed, use the LEFT or RIGHT but-
tons to toggle between.
5. Press ENTER to conrm your selection or press MODE to exit.
Dim Curve
Dim Curve - With this function you can change dimmer curve setting
for LED. See page 44 for the Dimmer Curve Chart.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
Vizi Q Wash7 System Menu
that “Function” is higlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “Fan Set” is displayed, and
press ENTER. The current setting will now be displayed.
3. “Head Fan” will now be displayed, press ENTER.
4. Use the LEFT or RIGHT buttons to make the adjustments to the
fan.
5. Press ENTER to conrm your selection or press the MODE button
to return to the main menu.
LCD.Set
Backlight - With this function you can have the LCD display after
2-60 minutes. Use this function to adjust the time.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “LCD.Set” is displayed,
press ENTER.
3. Press LEFT or RIGHT buttons, until “Backlight” is displayed, and
press ENTER.
4. “05m” (5 minutes) will be displayed, use the LEFT or RIGHT but-
tons to adjust the shuto time between 02m-60m or “O”.
5. Press ENTER to conrm your selection or press MODE to exit.
Flip Display - With this function you can rotate (ip) the display 180
degrees.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “LCD.Set” is displayed,
press ENTER.
3. Press LEFT or RIGHT buttons, until “Flip Display” is displayed,
and press ENTER.
4. Either “O” or “On” will be displayed, use the LEFT or RIGHT but-
Содержание
80- Vizi q wash7
- User instructions
- Warning
- Unpacking introduction customer support safety precautions features handling precautions registration mounting dmx set up 11 dmx control 2 dmx traits 3 21 color macro chart 2 system menu 3 operation 0 photometric chart 2 43 dimmer curve chart 4 fuse replacement 4 cleaning 5 trouble shooting 5 warranty 6 specifications 7
- Unpacking
- Table of contents
- Introduction
- Customer support
- Caution
- Screw one clamp each via a m12 screw and nut onto the omega holders insert the quick lock fasteners of the omega holders into the respective holes on the bottom of the vizi q wash7 tighten the quick lock fasteners fully clockwise install the second omega holder pull the safety cable through the holes on the bottom of the base and over the trussing system or a safe fixation spot insert the end in the carabine and tighten the safety screw
- Power supply
- Notice the suitable enviromental temperature for this light ing fixture is between 25 c to 45 c do not place this lighting fixture in an enviroment where the temperatures are under or above the temperatures stated above this will allow the fixture to run at its best and help prolong the fixture life
- Dmx 512
- Pin xlr dmx connectors
- Pin 5 do not use
- Pin 4 do not use
- Notice
- Not used
- Ground shield
- Data true signal
- Data compliment signal
- Conductor 5 pin xlr male in 3 pin xlr female out
- Be sure to follow figures two and three when making your own cables do not use the ground lug on the xlr connector do not con nect the cable s shield conductor to the ground lug or allow the shield conductor to come in contact with the xlr s outer casing grounding the shield could cause a short circuit and erratic behavior
- A male and female xlr connector on either end of the cable also remember that dmx cable must be daisy chained and cannot be split
- When longer runs of cable are used you may need to use a terminator on the last unit to avoid erratic behavior a terminator is a 110 120 ohm 1 4 watt resistor which is con nected between pins 2 and 3 of a male xlr connector data and data this unit is inserted in the female xlr connector of the last unit in your daisy chain to terminate the line using a cable terminator adj part number z dmx t will decrease the possibilities of erratic behavior
- Vizi q wash7 dmx set up
- Special note line termination
- Some manufactures use 5 pin dmx 512 data cables for data transmission in place of 3 pin 5 pin dmx fixtures may be implemented in a 3 pin dmx line when inserting stan dard 5 pin data cables in to a 3 pin line a cable adaptor must be used these adaptors are readily available at most electric stores the chart below details a proper cable conversion
- Pin xlr to 5 pin xlr conversion
- Vizi q wash7 system menu
- Vizi q wash7 color macro chart
- Adj products llc www adj com vizi q wash7 instruction manual page 23 adj products llc www adj com vizi q wash7 instruction manual page 22
- To use this function follow these instructions to adjust the address of your unit you must first go to the address that it is currently set to from there you can adjust the address first make sure all channels are set to the value of 0
- Set the dmx value of channel 3 to your desired start ing address this will take about 20 seconds before the unit accepts the new dmx address example if you want the address to be 57 you must first set
- On your dmx controller set the dmx value of channel 1 to the value 7
- Now set the dmx value of channel 2 to the value 7 to adjust the starting address between 1 and 255 to adjust the address between 256 and 511 set channel 2 to the value 8
- The address that is currently assingned to the unit then set channel 1 s value to 7 channel 2 s value to 7 and chan nel 3 s value to 57 wait 20 seconds and the address should change on the unit to 57
- Nd example if you want the address to be 420 you must first set the address that is currently assingned to the unit if you want the set the address to 420 set channel 1 s value to 7 channel 2 s value to 8 and channel 3 s to 164 256 164 420
- Stand alone auto program
- Master slave cofiguration auto program
- Intensity lux
- Beam opening m
- 1 3 5 8 10
- 1 2 3 4 5
- Fixture cleaning
- Ew kerkrade
- This fixture contains a automatic volt age switch which will auto sense the voltage when it is plugged into the power source
- Duty cycle none
- The netherlands
- Dmx 3 dmx channel modes 17 channels
- Tel 323 582 2650 fax 323 725 6100
- Dimensions 11 5 l x 8 w x 15 5 h
- Tel 31 45 546 85 00 fax 31 45 546 85 99
- Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice
- Colors rgbw
- Service adjgroup eu www adj eu
- Channels or 23 channels 19 channels or 23 channels
- S eastern ave los angeles ca 90040 usa
- Beam angle 7 58 degrees
- Powercon daisy chain 5 fixtures max 110v
- Auto sensing voltage
- X 200 x 400mm 300 x 200 x 400mm
- Power consumption 305w
- Adj products llc www adj com vizi q wash7 instruction manual page 46
- Working position any safe secure position
- Please note
- Adj products llc
- Weight 19 lbs 8 kgs
- Model vizi q wash7
- A d j supply europe b v
- Web www adj com e mail info americandj com
- Leds 7 x 40w rgbw 4 in 1 leds
- Warranty 2 year 730 days
- Led life 50 000 hrs
- Voltage 100 240v 50 60hz
- Junostraat 2
- Vizi q wash7 warranty
- Fuse 3a 120v 2a 240v
- Fixtures max 240v 11 fixtures max 240v
- Vizi q wash7 specifications
