ADAM AUDIO Sub7 [10/32] Controls

5.2 Controls on the rear panel

a) Mode

This push button allows you to choose between

• Auto On: woofer starts operation as soon as a musical

signal arrives, and stops after 15 minutes without a

signal.

• Auto Off: the unit is permanently working.

We recommend the ”Auto On” position. It minimises

power consumption and makes handling very easy.

b) Subwoofer Phase

With the Phase Switch you can alter the phase of the subwoofer relative

to the satellites. That means to change the polarity of the bass unit.

Depending on the distance between woofer and satellites, either 0° or

180° may be the better position.

We recommend to try out what position sounds better within your

system.

c) Satellite Filter

The satellites in a system can be driven full range or with a 85 Hz high

pass as recommended by Dolby® laboratories for use in surround set-

ups.

Recommendation: If possible the main signal should go into the

Subwoofer. Connect your satellites to the Subwoofer output, either

via XLR symmetrical or RCA asymmetrical. In many cases, clarity and

dynamic range of the speakers can be improved if they do not reproduce

very low frequencies since they do not have to deliver big amplitudes.

d) Foot Switch

The optional available footswitch switches the suboofer on respectively

off. Please note that by switching it off you also switch off the Satellite

Filter.
