ADAM AUDIO Sub7 [9/32] Controls

Sub7 Manual / english

On the front side you will ﬁnd two potentiometers, one for the volume and

one for the crossover frequency. Both the volume and the frequency can

also be controlled by the remote control. On the rear side, there are more

controls (satellite ﬁlter, phase switch, mode). The following tips are intended

to assist you at using the controls in the best manner.

5.1 Controls on the front panel and Remote control

a) Volume

Input Sensitivity control from -60 dB to +6

dB relative to 775 mV when used via the

symmetrical XLR input or relative to 250

mV when used via the asymmetrical Cinch

(RCA) input.

b) Frequency

The upper frequency limit of the unit

is variable and can be set to any value

between 50 and 150Hz. The 85Hz marker

indicates the recommendation of Dolby®

labs for surround sound settings. In many

cases, a slightly lower crossover frequency

delivers tighter bass response, for typical

near-midﬁeld monitors we recommend 70

to 75Hz as upper limit (i.e. -3 dB point in the

frequency response).

Please note: If you alter the frequency it is

advisable to check if an alteration of the

phase improves the sound quality.

5. Controls

FREQ

VOLUME
