American DJ® - www.americandj.com - Quad Phase Instruction Manual Page 11
American DJ® - www.americandj.com - Quad Phase Instruction Manual Page 12
Universal DMX Control: This function allows you to use a Elation®
universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Quad Phase is a four DMX channel DMX fixture. See page
13 for detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are
included with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 8 to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows a single unit or several units
linked together, to run to the beat of the music.
1. Tap the MENU button until “SOUN” is displayed, and press
ENTER.
2. Press the UP or DOWN button so that “On” is displayed.
The unit will now run to the beat of the music.
3. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Master-Slave Operation (Sound Active): This function will allow
you to link up to 16 units together and operate without a controller. The
units will be sound activated. In Master-Slave operation one unit will
act as the controlling unit and the others will react to the controlling
units programs. Any unit can act as a Master or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit find your desired show and set that show by
Quad Phase Operation Quad Phase Operation
pressiing the ENTER button.
3. On the slave units tap the MENU button until “SLND” is dis-
played, select your desired slave mode and Press ENTER.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Quad Phase UC3 Control
Stand by
Blackout the unit
Function
1. Synchronous Strobe
2. Two light Strobe
3. Sound Control
Rotation Speed
1-8
Mode
Strobe (LED OFF)
Chase (LED ON)
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 15 xtures maximum. After 12 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
Quad Phase Power Cord Daisy Chain
