Quad Phase Fuse Replacement

Quad Phase Cleaning

Quad Phase Trouble Shooting

Trouble Shooting: Listed below are a few common problems that

you may encounter, with solutions.

No light output from the unit;

1. Be sure you have connected your unit into a standard 120v wall

outlet.

Tapping on the microphone, quiet or high pitched sounds may

not activate the unit.

Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the

internal and external optical lenses and mirror should be carried out

periodically to optimize light output. Cleaning frequency depends on

the environment in which the fixture operates (I.e. smoke, fog residue,

dust, dew). In heavy club use we recommend cleaning on a monthly

basis. Periodic cleaning will ensure longevity, and crisp output.

1. Use normal glass cleaner and a soft cloth to wipe down the out-

side casing.

back in.

First unplug the power. The fuse holder is located next to the power

cord. Using a flat-head screw driver unscrew the fuse holder. Remove

the bad fuse and replace with a new one.

Quad Phase DMX Traits

Channel Value Function

1 0 - 255 COLOR SELECTION

1 - 16 COLOR 1

17 - 33 COLOR 2

34 - 50 COLOR 3

51 - 67 COLOR 4

170 - 186 COLOR 11

187 - 203 COLOR 12

204 - 220 COLOR 13

221 - 237 COLOR 14

238 - 255 COLOR 15

2 ROTATION

0 - 9 NO ROTATION

10 - 120 CLOCKWISE FAST - SLOW

121 - 134 NO ROTATION

135 - 245 COUNTER-CLOCKWISE

4 SHUTTER OPEN

0 - 15 OFF

16 - 255 OPEN
