APart MA125 Руководство по эксплуатации онлайн
MA125
OWNER’S MANUAL
MIXING AMPLIFIERSMIXING AMPLIFIERS
The MA125 is developed by
Audioprof nv
Lanteernhofstraat 90
BE-2100 Deurne
BELGIUM
info@apart-audio.com
www.apart-audio.com
Find more interesting audio solutions at www.apartaudio.com
Содержание
- Mixing amplifiers mixing amplifiers 1
- Owner s manual 1
- Before using your ma125 take a few minutes to read these instructions carefully this little time can avoid a lot of headaches afterwards 2
- Brackets are shipped along with your amplifier 2
- Important safety instructions 2
- Keep this manual for future reference 2 water and humidity are the biggest enemies of electric equipment operating it under moist conditions can even be dangerous 3 clean only with dry cloth 4 do not operate near heaters or place it on other apparatus which produce a lot of heat 5 be sure your unit is always connected to the electrical safety earth do not defeat the safety purpose of a grounding type plug if you have any doubt please consult your dealer or a qualified technician 6 take care for the power cord never use a damaged power cord and install it in such a way that no one can walk on it 7 only use accessories specified by the manufacturer 8 distorted sound indicates that operating conditions are bad decrease the volume check the speakers and sources connected or switch off the unit 9 disconnect the unit from the mains power supply when you do not use it for a longer period 10 when smoke ore bad smell comes from your ma125 switch off immediately and disconnect from mains 11 this 2
- Mixing amplifiers mixing amplifiers 2
- Safety information 2
- Technical specifications 2
- The ma125 complies with the ce standards 2
- The ma125 is a very compact professional pa mixing amplifier for commercial and industrial applications all microphone inputs have integrated speech filters he s able to drive 8 ohm or constant voltage loudspeaker lines 50 70 100v the amplifier has 4 microphone 4 selectable line inputs and one emergency telephone input mic input 1 is meant to be the main microphone paging input for its signal can be fed via the front ¼ trs phone jack or via a xlr3 din 5 or euro block connector at the back when needed two apart paging microphones can be wired in parallel on each mic input the ma125 has a three level priority system the emergency telephone input at the back has the highest priority its signal goes directly to the main amplifier bypassing any front control and an attenuator next to the input sets its level microphone input 1 has the second priority level with the control next to the din5 input the vox voice activated mute for microphone 1 can be activated and mutes all other signals excep 2
- The ma125 is the device to built professional industrial sound applications you can insert an extra equalizer such as the apart pxq2215 into the signal path or add extra power amps apart pa240p using the pre amp out power amp in rca connectors when shipped a rca bridge has been inserted 2
- When needed the signals mixed via your ma125 mixing amplifier can be recorded or distributed via the record output 2
- When the priority contact has been activated 24v dc max 6a will be available to activate priority relays of loudspeaker attenuators or other devices 2
- Any suggestion 3
- Front panel 3
- How to deal with 100v loudspeaker systems 3
- In fact working with 100v loudspeakers is rather simple when done in the right way each 100v loudspeaker has a 100v transformer which can be set to a certain power for example 1 5 3 or 6w as the example shows the sum of all loudspeaker settings should never exceed the amplifier s power specifications never use low impedance 8 ohm loudspeakers on a 100volt system even not one 3
- Mixing amplifiers mixing amplifiers 3
- More technically when your paging amp has a maximum output of 125 watts at 100v this means that the minimum impedance connecte d should be at least 80 ohm 100x100 125 to check your loudspeaker lines use a decent impedance checker example ap wm100 3
- Now you are ready to get the best result on distributing your music and messages to your audience your little giant is like a swiss knife which will astonish you and many others 3
- Suggestion apart audio com 3
- They are well appreciated and eventually rewarded send your ideas or suggestions to 3
- Troubleshooting 3
- Back panel 4
- Mixing amplifiers mixing amplifiers 4
