4•2
Relay G70 & G75 Receiver
Relay G70/G75 Advanced Guide
8. Aux In: An Auxiliary Input for wired performance - handy for keeping another guitar plugged in, or
as a “safety net” in case of forgotten or failing Transmitter batteries. The default mode for the Aux
In is “Always On,” as set in the global preferences. In this mode the Aux In is active in any Scene
where the assigned Transmitter is O, or in any Scene where the Aux In is set as the Channel
input. If the global preference is set to “Scene Only” the Aux In will only be active in Scenes
where it is the designated Channel input.
9. Home Button: This navigation button returns the LCD to home screen display content. See “The
Home Screen” on page 4•3.
10. Nav/Select Encoder: This is your primary navigation control. Rotate the Encoder knob to choose a
selection - push it to activate the current selection. When the Home Screen is displayed, the
Encoder allows you to scroll up or down through all the Scenes you have created. Press the
Encoder to activate a Scene. Also see “Edit Mode” on page 5•1 for details on navigating the
editable parameters for your device.
11. Edit Button: Press to enter Edit Mode where you can access Scene and Input parameters. See
“Edit Mode” on page 5•1.
12. Select/Mute Switch: Use this footswitch (G70) or button (G75) to cycle sequentially through existing
Scenes. Press and hold the switch for 2 seconds to Mute all outputs and/or activate the internal
Tuner.
Note: The Receiver’s built-in Tuner is available only when nothing is plugged into the Tuner Output.
13. Switch Color Ring: The color of this LED ring surrounding the Select/Mute switch is user-dened per
Scene, providing a visual indicator for which Transmitter is currently active - see the Transmitter
details on page 3•1.
The Color Ring maintains steady brightness when the RF signal is good and ickers whenever
the RF reception is poor. It also blinks to indicate several dierent states - see “Edit Mode” on
page 5•1 for details.
14. LCD Display: This monochrome LCD is the main information source for your wireless setup. Its
Home Screen displays active Transmitter Channel or Input, active Output Routing and Battery
Life. Its Edit Mode screen displays settings for cable tone, gain, and other preferences.
15. 9VDC Input: Optional 9VDC 500mA DC.
Note: The compatible Line 6 DC-1g or DC-3g 9V power supplies are available separately from your Line 6
dealer, or from the Line 6 Online Store.
16. Audio LED: Lights green to indicate audio reception. Lights red to indicate clipping. The Audio
LED is also utilized as a tuning indicator when your Receiver is in Tuner Mode - It turns red when
sharp or at, and green when within ± 3 cents of the target note (see page 5•13 for more about
the built-in Tuner).
17. Remote (G75 only): Connect a momentary footswitch* to provide foot-operated Scene changes,
similar to the footswitch functionality on the G70.
*Works with either momentary closed or open footswitch types. The Remote jack automatically detects
when a footswitch is connected, and can detect polarity switch changes as well.
