8 | English 1 609 929 T59 • 28.1.09
To switch on the measuring tool, press the On/Off
switch 4.
After switching on the measuring tool, the measuring
accuracy level “medium” is always set.
To switch the measuring tool off, press the “on/off”
button 4.
When no pushbutton on the measuring tool is
pressed for approx. 5–8 minutes and when no laser
beam is impinged upon the reception area 3 for
5–8 minutes, the measuring tool switches off auto-
matically to save the batteries.
Direction Indicators
The display 1 has 7 separate reception channels,
which indicate the position of the detector with refer-
ence to the laser plane. The closer the laser beam
comes to the centre mark 12 of the detector, the more
bars are indicated in direction indicator 8 and 9.
(see figure B)
Direct the reception area 3 toward the line laser.
Slowly move the detector upward or downward until
the direction indicators 8 and 9 appear on display 1
and/or an audio signal can be heard. According to the
working conditions and the requested accuracy,
select the sensitivity with button 5.
Move the detector upward when direction indicator 9
is lit (with the speaker volume on, a short audio signal
is heard). Move the detector downward when direc-
tion indicator 8 is lit (with the speaker volume on, a
long audio signal is heard). When the centre of the
reception area 3 is reached, the centre mark 12 on
display 1 is indicated and a continuous audio signal is
heard.
Memory Function
If the laser beam leaves the reception area, the last
laser beam position is saved.
Electronic Filter
The electronic filter protects the measuring tool against
bright sunlight and electromagnetic interference.
Maintenance and Service
Maintenance and Cleaning
Keep the measuring tool clean at all times.
Do not immerse the measuring tool into water or other
fluids.
Wipe away debris or contamination with a dry, soft
cloth. Do not use cleaning agents or solvents.
If the measuring tool should fail despite the care taken
in manufacturing and testing procedures, repair
should be carried out by an authorized after-sales
service centre for Bosch power tools.
After-sales Service and Customer
Assistance
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: +44 (0844) 736 0109
Fax: +44 (0844) 736 0146
E-Mail: SPT-Technical.de@de.bosch.com
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: +353 (01) 4 66 67 00
Fax: +353 (01) 4 66 68 88
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: +61 (01300) 307 044
Fax: +61 (01300) 307 045
Inside New Zealand:
Phone: +64 (0800) 543 353
Fax: +64 (0800) 428 570
Outside AU and NZ:
Phone: +61 (03) 9541 5555
www.bosch.com.au
People’s Republic of China
Website: www.bosch-pt.com.cn
China Mainland
Bosch Power Tools (China) Co., Ltd.
567, Bin Kang Road
Bin Jiang District 310052
Hangzhou, P.R.China
Service Hotline: 800 8 20 84 84
Tel.: +86 (571) 87 77 43 38
Fax: +86 (571) 87 77 45 02
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: +852 (21) 02 02 35
Fax: +852 (25) 90 97 62
E-Mail: info@hk.bosch.com
www.bosch-pt.com.cn
OBJ_BUCH-927-001.book Page 8 Wednesday, January 28, 2009 10:12 AM
