18 | English
1 609 929 T56 24.2.09
Technical Data
Assembly
Inserting/Replacing the Battery (see figure A)
Alkali-manganese batteries are recommended for the measuring tool.
Remove the protective rubber sleeve 3.
Open the battery compartment 6.
When inserting batteries, pay attention to the correct polarity accord-
ing to the representation on the inside of the battery compartment.
Always replace all batteries at the same time. Only use batteries from
one brand and with the identical capacity.
Close the battery compartment and remount the protective rubber
sleeve on the measuring tool.
f Remove the batteries from the measuring tool when not
using it for extended periods. When storing for extended periods,
the batteries can corrode and discharge themselves.
Cross-line Laser 58-iLMXL
Max. working range 30 m
Aperture angle 120°
Levelling Accuracy ± 0.4 mm/m
Self-levelling range, typically
±
Levelling duration, typically 3s
Laser class 2M
Laser type 635 nm, <1 mW
Tripod mount 1/4" x 20
Batteries 3x1.5VLR6(AA)
Operating life time, approx. 20 h
Weight according to EPTA-Procedure 01/2003 0.9 kg
