the deflector (filtering version).

10. Only for filtering version: mount deflector F onto the

trellis and fix it with 4 screws to the apposite bracket and

finally connect the discharge tube to the connection ring

placed on the deflector.

11. Connect the electricity to the domestic power. Power

must be supplied only after the installation has been

completed.

12. Put the nuts equipped with fixing hooks inside the

sections of the upper and lower flues in correspondence

with the rectangular slots. A total of 14 nuts should be

mounted.

13. Couple the two upper sections of the flue to cover the

trellis so that one of the slits present on the sections is

placed on the same side of the command panel and the

other on the opposite side.

Screw the two sections up with 8 screws (4 per side –

also see the plan diagram for coupling the two sections).

14. Fix the upper flue set to the trellis near the ceiling with

two screws (one per side).

15. Couple the two lower sections of the flue to cover the

trellis using 6 screws (3 per side - also see the plan

diagram for coupling the two sections).

16. Insert the lower section of the flue into the apposite

housing to cover the motor space and the electrical

connection box completely and fix with two screws from

inside the hood.

17. Apply the 2 tabs (supplied) to cover the fixing points of

the sections of the lower flue (ATTENTION! THE TABS

FOR THE LOWER FLUE ARE RECOGNISABLE

BECAUSE THEY ARE NARROWER AND LESS DEEP).

The larger and deeper tabs are those to use for the upper

flue and are to be cut to measure.

18. Supply the electrical power again acting on the

central electrical panel and check the correct functioning of

the hood.

Installation wall model

When the vapour catcher is disassembled, it must be fixed as

shown in Fig. a,b.

The electric connection box must be assembled as shown in

Fig. c,d,e.

Fig. 9

1. Drawing a line on the wall with a pencil up to the ceiling,

corresponding to the centre line, will make the installation

operations easier.

2. Apply the perforation diagram to the wall: the vertical

centre line printed on the perforation diagram should

correspond to the centre line drawn on the wall. In

addition, the lower edge of the perforation diagram

corresponds to the lower edge of the hood.

3. Make holes as indicated on the template, insert the wall

dowels and screw 2 screws into the upper holes, leaving

a space of about 1 cm between the head of the screw

and the wall.

Note: Always make the holes indicated on the template.

The upper 2 are for hooking the hood up while the lower

holes (generally 1 central or more lateral) are for the

definitive and safety fixing.

4. Apply flues support bracket „G“ to the wall touching the

ceiling. Use the flues support bracket as a perforation

diagram (the small slot in the support must coincide with

the line previously drawn on the wall, if present), and

mark two holes with a pencil. Make the holes and insert 2

dowels.

5. Fix the flues support bracket to the wall with 2 screws.

6. Hang the hood to the two upper screws (see installation

phase 3).

7. Introduce and screw the screws (and washer(s)) up into

the hole(s) for the definitive fixing (COMPULSORY!!).

Then, having checked the setting of the hood, TIGHTEN

ALL THE upper and lower SCREWS.

Note: the lower fixing points are visible removing the fats

filters and they are at the sides and/or at the centre of the

hood (after having removed the frame of the carbon filter,

if present, in the latter case).

In any case, we recommend using the lateral holes, when

available, to increase the stability of the hood.

8. Connect a tube (tube and bands for fixing not supplied, to

be purchased) for discharging the fumes to the

connection ring placed over the aspiration motor unit.

The other end of the tube should be connected to a

device for expelling fumes on the outside of the hood in

the aspiration version. If you want to use the filtering

version, fix deflector F to flues support bracket G and

connect the other end of the tube to the connection ring

placed on deflector F.

9. Connect the electricity.

10. Apply the flues and fix them above with 2 screws (10a) to

flues support bracket „G“ (10b).

11. Slide the lower section of the flue down to cover the

aspiration set until inserting it completely into the

apposite housing over the hood. Remount the carbon

filter frame and the fat/s filter/s and check the perfect

functioning of the hood.
