BRIEF DESCRIPTION

The cooker hood was designed to remove kitchen fumes. It

requires installation of a conduit discharging used air to the

outside. The conduit should not be longer than 4-5 m. The

hood can operate as an odour absorber after installation of

an charcoal filter. In such case a conduit discharging used air

to the outside is not necessary, but it is recommended to

install an air exhaust guide.

The cooker hood is an electrical appliance manufactured

according to class II of shock protection.

It has its own lighting and an exhaust fan which can be set to

one of 3 rotational speeds.

The hood was designed for permanent installation on a

vertical wall over a gas or electric cooker.

LOCATION DRAWING

Arrangement of the functional elements:

1. Hood body, equipped with lights, engines unit and

electronic programmable control;

2. Exhaust outlet;

3. V-flap for an exhaust guide;

4. Metal grease filter;

5. Extending fume deflector with filter.
