Aqua Mini Full DC Inverter Unitary Chiller 50Hz
10
4. Specifications
Model
MGRH5A-PA1Z MGRH7A-PA1Z
Power supply V-Ph-Hz
220-240, 1, 50 220-240, 1, 50
Cooling*(1)
Capacity kW 5.0 7.0
Input kW 1.55 2.25
Cooling*(2)
Capacity kW 6.57 7.88
Input kW 1.27 1.84
Heating*(3)
Capacity kW 5.5 8.0
Input kW 1.7 2.5
Heating*(4)
Capacity kW 6.32 8.29
Input kW 1.52 2.13
EER*(1) kW/kW 3.23 3.11
EER*(2) kW/kW 5.16 4.28
Max. input consumption kW 2.8 3.0
Max. input current A 14.6 15.6
Compressor
Model SNB172FJGMC SNB172FJGMC
Type ROTARY ROTARY
Brand Mitsubishi Electric Mitsubishi Electric
Capacity kW 5.46 5.46
Input kW 1.64 1.64
Rated load current A 8.1 8.1
Locked rotor Amp A 29.5 29.5
Thermal protecto
r
Inner Inner
Refrigerant oil ml FV50S,400 FV50S,400
Outdoor fan
motor
Model
WZDK170-38G-1 WZDK170-38G-1
Type
DC Motor DC Motor
Brand
NIDEC SHIBAURA NIDEC SHIBAURA
Input
W 170 170
Speed
r/min 820 820
Outdoor coil
Number of rows 22
Tube pitch(a)× row pitch(b) mm
22×19.05 22×19.05
Fin spacing mm 1.6 1.6
Fin type Hydrophilic aluminum foil Hydrophilic aluminum foil
Tube outside dia. and type mm
φ7.94 φ7.94
Inner
g
rooved co
pp
er tube Inner
g
rooved co
pp
er tube
Coil length ×height mm 885×880 885×880
Number of circuits 66
Water pump
Type RS15/6-3-WILO RS15/6-3-WILO
Input (H/M/L) W 93/67/46 93/67/46
Pumping head m 5.5 5.5
Outdoor air flow m
3
/h 5100 5100
Throttle EXV+capillary EXV+capillary
Outdoor noise level (sound pressure)*(3) dB(A) 58 58
Water flo
w
m
3
/h 0.86 1.20
The plate heat-exchanger water pressure
drop
kPa 15 15
The Max. and Min. water inlet pressure kPa
500/150 500/150
Outdoor
unit
Net dimension (W×H×D) mm 990×966×354 990×966×354
Packing dimension
(W×H×D)
mm 1120×1100×435 1120×1100×435
Net/ Gross weight kg 81
/
91 81/91
Refrigerant
Type R410A R410A
Charged volume kg 2.5 2.5
Connection
wiring
Power wi
r
e mm
2
3×2.5 3×2.5
Signal wire mm
2
3×0.75 3×0.75
Pipe
diameter
Water inlet/outlet inch 1’’ 1’’
Control Wired controlle
r
Wired controlle
r
Ambient temperature ℃ Cooling: -5℃~46℃; Heating: -15-27℃(Antifreeze must be added below 5℃)
Water outlet temperature range ℃ Cooling: 4~20 ℃; Heating: 30~55 ℃
Note: Specifications are bas
ed on the following conditions:
1. Cooling: (*1) chilled water inlet/outlet temperature: 12/7°C,outdoor ambient temperature 35°C DB.
(*2) chilled water inlet/outlet temperature: 23/18°C,outdoor ambient temperature 35°C DB.
