Aqua Mini Full DC Inverter Unitary Chiller 50Hz
20
9. Capacity Tables
MGRH5A-PA1Z
Cooling
Chilled
water
outlet
temp.
Ambient temp.(℃)
21.00 25.00 30.00 35.00 40.00 46.00
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
(℃)
kW kW W/W kW kW
W/
W
kW kW W/W kW kW W/W kW kW W/W kW kW W/W
5.00 5.60 1.37 4.10 5.27 1.41 3.75 4.97 1.45 3.43 4.70 1.50 3.14 4.40 1.57 2.80 4.05 1.65 2.46
6.00 5.79 1.39 4.17 5.44 1.43 3.81 5.13 1.47 3.48 4.85 1.52 3.19 4.54 1.59 2.85 4.19 1.67 2.50
7.00 5.99 1.41 4.23 5.63 1.46 3.86 5.30 1.50 3.53 5.00 1.55 3.23 4.70 1.63 2.88 4.33 1.71 2.53
8.00 6.17 1.46 4.24 5.80 1.50 3.86 5.45 1.55 3.52 5.14 1.60 3.22 4.83 1.68 2.88 4.46 1.76 2.53
9.00 6.35 1.47 4.31 5.95 1.52 3.93 5.60 1.56 3.58 5.27 1.61 3.27 4.96 1.69 2.93 4.58 1.78 2.58
10.00 6.59 1.49 4.41 6.17 1.54 4.01 5.80 1.59 3.65 5.45 1.64 3.33 5.14 1.72 2.99 4.75 1.80 2.63
11.00 6.77 1.51 4.49 6.34 1.55 4.08 5.95 1.60 3.71 5.59 1.65 3.38 5.27 1.73 3.04 4.88 1.82 2.68
12.00 6.93 1.53 4.53 6.48 1.58 4.11 6.07 1.63 3.73 5.70 1.68 3.40 5.38 1.76 3.06 4.99 1.85 2.70
13.00 7.05 1.54 4.57 6.59 1.59 4.14 6.17 1.64 3.76 5.79 1.69 3.43 5.47 1.77 3.08 5.08 1.86 2.72
14.00 7.23 1.55 4.65 6.75 1.60 4.21 6.31 1.65 3.82 5.92 1.70 3.48 5.60 1.79 3.13 5.20 1.88 2.77
15.00 7.32 1.56 4.69 6.83 1.61 4.24 6.38 1.66 3.85 5.97 1.71 3.49 5.66 1.80 3.15 5.26 1.89 2.79
16.00 7.50 1.58 4.76 6.99 1.63 4.30 6.53 1.68 3.90 6.11 1.73 3.54 5.79 1.81 3.19 5.39 1.90 2.83
17.00 7.60 1.58 4.80 7.07 1.63 4.33 6.60 1.68 3.92 6.17 1.74 3.55 5.85 1.82 3.21 5.45 1.91 2.85
Note: The inlet/outlet w
ater temperature difference is 5°C.
Heating
Note: The inlet/outlet w
ater temperature difference is 5°C.
Hot
water
outlet
temp.
Ambient temp.(℃)
-10 -6 -2 2 7 10 13
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
(℃) kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W
40.00 3.41 1.06 3.21 4.26 1.21 3.53 5.02 1.34 3.74 5.58 1.46 3.82 6.06 1.54 3.94 6.79 1.63 4.17 7.81 1.76 4.44
41.00 3.30 1.09 3.04 4.13 1.23 3.35 4.87 1.37 3.55 5.42 1.49 3.64 5.89 1.57 3.76 6.59 1.66 3.97 7.57 1.80 4.21
42.00 3.21 1.11 2.90 4.02 1.26 3.19 4.74 1.40 3.39 5.28 1.52 3.47 5.75 1.60 3.59 6.42 1.70 3.78 7.36 1.83 4.02
43.00 3.13 1.13 2.77 3.93 1.28 3.06 4.64 1.43 3.25 5.17 1.55 3.33 5.64 1.63 3.45 6.28 1.73 3.63 7.19 1.87 3.84
44.00 3.07 1.15 2.66 3.86 1.31 2.94 4.56 1.46 3.13 5.09 1.58 3.21 5.56 1.67 3.33 6.18 1.77 3.50 7.05 1.91 3.70
45.00 3.03 1.18 2.57 3.81 1.34 2.85 4.50 1.49 3.03 5.03 1.62 3.12 5.50 1.70 3.24 6.11 1.80 3.39 6.96 1.95 3.58
46.00 2.97 1.19 2.50 3.74 1.35 2.77 4.43 1.50 2.95 4.95 1.63 3.04 5.42 1.72 3.16 6.00 1.82 3.30 6.83 1.97 3.48
47.00 2.88 1.21 2.37 3.63 1.38 2.64 4.31 1.53 2.81 4.82 1.66 2.90 5.28 1.75 3.02 5.84 1.86 3.15 6.64 2.00 3.31
48.00 2.77 1.25 2.21 3.49 1.42 2.46 4.15 1.58 2.63 4.65 1.71 2.71 5.10 1.80 2.83 5.63 1.91 2.94 6.38 2.07 3.09
49.00 2.61 1.30 2.01 3.31 1.48 2.24 3.93 1.64 2.40 4.41 1.78 2.48 4.84 1.88 2.58 5.34 1.99 2.68 6.04 2.15 2.81
50.00 2.45 1.36 1.79 3.10 1.55 2.00 3.69 1.72 2.14 4.14 1.87 2.21 4.55 1.97 2.31 5.01 2.09 2.40 5.66 2.26 2.51
