Setting the cutting height
456403_a 35
Pull item (2-6).
Setting the cutting height (10)
1 Open the lever up and turn it a quarter turn
clockwise in the direction of [lock symbol
opened].
➯
The cutting height adjustment is unlo-
cked.
2 Pull the lever upwards.
➯
Lawn cutting height is increased.
3 Push the lever downwards.
➯
Lawn cutting height is reduced.
4 Then turn the lever a quarter turn anticlock-
wise in the direction of [lock symbol closed]
and engage.
➯
Cutting height adjustment is locked.
5 Fold the lever down and close the cover (2-6).
ADVICE
The cutting height varies in the range
from 3 - 6 cm lawn height. It can be ad-
justed in five steps of 6 mm each.
BATTERY
The integrated battery is partially charged on
delivery. During normal operation, the battery
of the Robolinho is regularly recharged.
When the battery charge reaches 0%, the
Robolinho automatically returns to its base
station in order to charge the battery.
➯
Interrupting charging does not damage
the battery.
The base station is equipped with an elec-
tronic control unit with a monitoring function.
This automatically terminates the charging
procedure when a 100% charge status is re-
ached.
The battery status is shown on the display.
Make sure the charging contacts (10-1) of the
base station have adequate contact with the
contact surfaces (10-2) on the Robolinho.
The temperature range for charging should
be between 0 and 40 °C.
The built in protection circuit prevents the
battery from being charged at temperatures
above 45 °C, in order to prevent irreparable
damage to the battery.
If the operating time of the battery is reduced
in spite of it being fully charged, have the bat-
tery replaced by a new genuine battery. This
task should be carried out by an AL-KO dea-
ler, technician or service partner.
If the battery charge level has dropped be-
low the threshold set by the manufacturer as
a result of ageing or excessively long storage,
this means it cannot be recharged any longer.
Have the battery and the monitoring electro-
nic control unit checked by an AL-KO dealer,
technician or service partner, and renew it if
necessary.
The battery status is shown on the display.
Check the battery status after about 3 months
by switching on the Robolinho and reading off
the battery status. If necessary, place it in the
base station for charging.
In case of leakage of electrolyte must be rin-
sed with water / neutralizer. In case of contact
with eyes, so a doctor should be consulted.
ADVICE
The battery has been tested according
to the UN handbook. Therefore, it is not
subject to national and international re-
gulations governing substances of con-
cern, whether it is an individual part or
has been installed in the machine.
MAINTENANCE
CAUTION!
Before performing any maintenance
STOP button!
DANGER!
Danger of injury due to the cutting bla-
des!
During transport, always keep the cutting
blade plate facing away from your body.
Check Robolinho, base station and cable re-
gularly for damage
Have damaged parts and batteries replaced
or repaired by an AL-KO dealer, technician or
service partner
Transport
Only carry the Robolinho by its deck.
Stop the Robolinho using the [STOP key]
(13-2).
Switch off the Robolinho using the [ON/OFF
key] (13-7).
DANGER!
Danger of injury due to the cutting bla-
des!
During transport, always keep the cutting
blade plate facing away from your body.
