Champion HT625R - деталировка [5/6] Slp600c ga hedge trimmer

Champion HT625R - деталировка [5/6] Slp600c ga hedge trimmer

序号新ERP编码 ERP编码数量

Ser.NO. NEW Erp NO. Erp NO.

Qty

2-1

02020070064 6961 护刃器 Safeguard 1

2-2

02020070066 6963 刀片固定板 Settle plate 1

2-3

02020070063 6960 刀片 Blader 1

2-4

02020160144 6722 调整滑块 Spacer 7

2-5

02020070065 6962 刀片托架 Blader backstop 1

2-6

03010070020 9724 螺钉GB5789黑色 Screw 4

2-7

02020070101 6964 刀片护罩116C黄 Saft guard 1

2-8

03010110073 6755 螺钉组合黑色 Screw 6

2-9

70070080064 6745 齿轮箱盖 Gear case lid 1

2-10

02020160021 6731 长垫片 Plate 2

2-11

02070010105 6729 密封垫 Gasket 1

2-12

02090030003 6730 毛毡垫 Felt 1

2-13

03010010010 1164 内六方螺钉 GB70黑色 Screw 2

2-14

03010010021 1173 内六角螺钉 GB70黑色 Screw 1

2-15

02020160215 6728 固定块 Retainer 1

2-16

02020090008 6734 传动臂 Transmission arm 2

2-17

03090010022 6772 轴承 Bearing 2

2-18

02020090043 6733 偏心轮 Eccenter 1

2-19

02020090004 6735 齿轮轴 Geardrive 1

2-20

03010010026 6689 内六角螺钉 GB70黑色 Screw 4

2-21

03120020003 4538 孔挡圈 GB893 Ring 1

2-22

03090010020 2715 轴承 Ball bearing 2

2-23

02020090045 6732 偏心轮轴 Eccenter spindle 1

2-24

02020160465 6723 增强垫板 Plate 1

2-25

03030060009 4319 防松螺母 GB889.1彩 Nut 5

2-26

70070010028 齿轮箱（不带孔） Gear case 1

2-27

03010110043 3697 黄油嘴 Butter nib 1

2-28

02020050027 5489 被动盘焊合 Drum 1

2-29

70030030348 6972 防护手柄黑色 Handle 1

2-30

03020020033 4335 螺钉组合 GB9074.4黑色 Screw 2

2-31

03010040010 4239 自攻丝 GB845黑色 Screw 5

2-32

70030070251 6966 右操纵手柄黑色 Control handle 1

2-33

70030160107 6967 手把定位块116C黄 Bracket 1

2-34

02020110054 6957 复位弹簧 Spring 1

2-35

03010040055 7349 自攻丝GB9074.18白色 Screw 1

2-36

03040010013 4256 加大平垫 GB96 Washer 1

2-37

02050050217 6954 停车开关组合116C黄 Stop button comp 1

（SLP600C(GA) HEDGE TRIMMER)

名称 Part Name
