PARTS LIST
REPLACES
2
Note: Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
106--232761
136 & 141
DAT E
12/10/03
106--232761--6/11/03
r
6
3
7
8
9
13
16
15
12
5
4
1
2
10
11
14
1 530029813 Turbo Air Cleaner Assembly
2 530019203 Seal -- Turbo Clean
3 530029814 Intake Sleeve
4 530053435 Impulse Seal
5 530015814 Screw
6 530037465 Adapter -- Carb.
7 530019172 Carburetor Gasket
8 ------ -- Carburetor
Zama -- C1Q--w6
530035482 WT--542 (Walbro)
530069629 WT--289 (Walbro)
530071510 WT--540 (Walbro)
530071692 WT--660 US/Can/Mex
530071704 WT--660 Export Only
9 Grommet--Final
Description
10 530047767 Plate -- Support
1 1 530015896 Screw
12 530036582 Air Filter -- Bottom
13 530015968 Stud -- Carb.
14 530016008 Nut
15 53002981 1 Air--Filter -- Top
16 530015899 Screw
17 530016044 Screw
18 530069415 Muffler Kit (Includes 17,19,20,21 & 22)
19 530037254 Muffler Cover
20 530029810 Spark Arrestor Screen
21 530037246 Muffler Diffuser
22 530037251 Muffler Body
23 530015902 Muffler Bolt
24 Assy. --Bearing and Seal
25 530029794 Crankshaft & Rod Assembly
Part No. Ref. Part No. DescriptionRef.
17
20
22
21
23
24
18
19
25
= NEW PART NUMBER FOR THIS IPLn
= REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED A T END OF IPL)
D
K
=
THESE PARTS ARE ILLUSTRATED FOR CLARITY. ORDER COMPLETE ASSEMBLY.
KKKK K
KKKKK
KKKKKn
