R
POULAN PRO PARTS LIST
PARAMOUNT PARTS LIST
R
WEED EATER PARTS LIST
R
R
PARTS LIST
REPLACES
6
Note: Illustration may differ from actual model due to design changes
PARTS LIST NO.
PAGE NO.
MODEL(s)
106--232761
136 & 141
DAT E
12/10/03
106--232761--6/11/03
r
Bearing
530016147
Seal
530019170
Assy---Bearing & Seal
530056363
Please note if your saw has the seperate bearing and seal or the new one piece design, and order parts
accordingly .
(PleaseNote:Thedifferentstyleswillnot
interchange.)
TWO P IECE STYLE ONE PIECE STYLE
= NEW PART NUMBER FOR THIS IPLn
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
D
K
=
THESE PARTS ARE ILLUSTRATED FOR CLARITY. ORDER COMPLETE ASSEMBLY.
LLLLL
LLLLL
Service Reference
--- --- --- A s s y --- C y l i n d e r ( i n c l s . c a p )
530069940 136
530069941 141
530049794 Cap --- Crankcase
530056363 Assy--- Bearing & Seal
Part No. Description
Part No. Description
--- --- --- A s s y --- C y l i n d e r ( i n c l s . c a p )
530069417 136
530069414 141
530019170 Seal
530016147 Bearing
LLLLL
LLLLL
Service Reference
Previous Style
530037466
Current Style
530035587
Use the grommet shown above with the
following carburetors:
Z a m a C 1 Q --- W 6
W a l b r o W T --- 2 8 9
W a l b r o W T --- 5 4 0
W a l b r o W T --- 5 4 2
(PleaseNote:Thedifferentstyles
will
not
interchange.)
Use the grommet shown above with the
following carburetors:
W a l b r o W T --- 6 6 0
(PleaseNote:Thedifferentstyles
will
not
interchange.)
