- 19 -
2-3 Advanced
` Intel(R) Smart Connect Technology
& ISCT Support
Enables or disables Intel
®
Smart Connect Technology. (Default: Disabled)
` SIO Misc Functions
& ErP
Determines whether to let the system consume least power in S5 (shutdown) state. (Default: Disabled)
Note: When this item is set to Enabled, the following functions will become unavailable: PME event wake
up, power on by mouse, power on by keyboard, and wake on LAN.
& Case Open
Displays the detection status of the chassis intrusion detection device attached to the motherboard CI
header.Ifthesystemchassiscoverisremoved,thiseldwillshow"Open",otherwiseitwillshow"Close."
To clear the chassis intrusion status record, set Reset Case Open Status to Enabled, save the settings
to the CMOS, and then restart your system.
& Power Loading k
Enables or disables dummy load. When the power supply is at low load, a self-protection will activate causing
it to shutdown or fail. If this occurs, please set to Enabled. AutoletstheBIOSautomaticallycongurethis
setting. (Default: Auto)
` H/W Monitor
& CPU Temperature (DTS)/System Temperature
Displays current CPU/system temperature.
& CPU/System Fan Speed
Displays current CPU/system fan speed.
& Vcore/VCC3/+12V/VCC/CPU_VAXG/3VDUAL/DDR1_35VIO
Displays the current system voltages.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Main
Power Loading [Auto] k
` Hardware Monitor
` Intel(R) Smart Connect Technology
` SIO Misc Functions
` CPUConguration
` PPMConguration
` ThermalConguration
` IDEConguration
` NetworkStackConguration
` CSMConguration
` USBConguration
` Realtek PCIe GBE Family Controller (MAC:74:D4:35:1D:21:FF)
` SIOConguration
gf: Select Screen
hi: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Boot Save & ExitSecurityChipsetAdvanced
k Only for GA-J1900N-D2H.
