- 7 -
1-2 ProductSpecications
CPU Built in with an Intel
®
Dual-Core Celeron
®
J1800 SoC (2.41 GHz)j
Built in with an Intel
®
Quad-Core Celeron
®
J1900 SoC (2.0 GHz)k
* Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage
to these components.
1 MB Cachej
2 MB Cachek
Memory 2 x 1.35V DDR3L DIMM sockets supporting up to 8 GB of system memory
* If only one DDR3L memory module is to be installed, be sure to install it in the
SODIMM_1 socket.
Dual channel memory architecture
Support for DDR3L 1333 MHz memory modules
Support for non-ECC memory modules
Onboard
Graphics
Integrated in the SoC:
- 1 x D-Sub port, supporting a maximum resolution of 2560x1600
- 1 x HDMI port, supporting a maximum resolution of 1920x1080
Audio Realtek
®
ALC887 codec
HighDenitionAudio
2/4/5.1/7.1-channel
* Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomodule
and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out
LAN Realtek
®
GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x1 slot
1 x Mini PCI Express x1 slot
* This socket does not support USB Bluetooth signals.
(The PCI Express x1 slots conform to PCI Express 2.0 standard.)
Storage Interface SoC:
- 2 x SATA 3Gb/s connectors
USB SoC:
- 1 x USB 3.0/2.0 port on the back panel
SoC + GL850S USB 2.0 Hub:
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through
the internal USB header)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
2 x SATA 3Gb/s connectors
1 x USB 2.0/1.1 header
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x serial port header
1 x parallel port header
1 x S/PDIF Out header
j Only for GA-J1800N-D2H.
k Only for GA-J1900N-D2H.
