- 23 -
2-4 Chipset
& Realtek LAN Controller
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled.
` North Bridge
This section provides information on the installed memory size and memory/onboard graphics-related
congurationoptions.
` IntelIGDConguration
Thissectionprovidesonboardgraphics-relatedcongurationoptions.
& MAX TOLUD
AllowsyoutocongurethemaximumTOLUDvalue.(Default:Dynamic)
` South Bridge
` USBConguration
ThissectionprovidesyouwithcongurationoptionsfortheUSBcontroller,suchasenabling/disablinga
specicUSBportandsupportforcertainfeatures.
` PCIExpressConguration
ThissectionprovidesyouwithcongurationoptionsforthePCIExpressbus,suchasenabling/disabling
aspecicPCIExpresschannelandspeedconguration.
& Audio Controller
Enables or disables the onboard audio function. (Default: Enabled)
If you wish to install a 3rd party add-in audio card instead of using the onboard audio, set this item to
Disabled.
& High Precision Timer
Enables or disables High Precision Event Timer (HPET) in the operating system. (Default: Enabled)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Main
Realtek LAN Controller [Enabled]
` North Bridge
` South Bridge
gf: Select Screen
hi: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
