GA-J1800N-D2H/GA-J1900N-D2H Motherboard Layout
Box Contents
5 GA-J1800N-D2H or GA-J1900N-D2H motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
KB_MS
CPU_FAN
Intel
®
J1800 SoCj
Intel
®
J1900 SoCk
ATX
GA-J1800N-D2H/GA-J1900N-D2H
F_AUDIO
SO-DIMM_2
SO-DIMM_1
BAT
F_PANEL
ATX_12V
HDMI
CODEC
M_BIOS
LPT
COM
USB_LAN
PCIEX1
F_USB
GL850S
Realtek
®
GbE LAN
iTE
®
Super I/O
SYS_FAN
VGA
SPDIF_O
CI
AUDIO
MINI_PCIE
R_USB
USB30
SATA2
CLR_CMOS
0
1
j Only for GA-J1800N-D2H.
k Only for GA-J1900N-D2H.
- 4 -
