Fulgor Milano FQH 900 X [8/52] Instructions for using maintaining and installing the hood

EN - 5

INSTRUCTIONS FOR USING, MAINTAINING AND INSTALLING THE HOOD

ATTENTION: The hood must only be installed by a qualified technician.

The company accepts no liability if it is installed by an unauthorised person.

Please read these instructions carefully before beginning the installation. Conserve this handbook together with the

hood

WARNINGS

This appliance can be used by children aged from 8 years and above and persons with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children

without supervision.

Before cleaning or performing any periodic or urgent maintenance to the hood, ensure the power is turned

off by removing the plug from the socket and turning the main switch to 0 (off).

Do not connect the hood to any piping used for combustion appliances, such as burners, boilers or fire-

places.

Check that the main power supply corresponds to the voltage required by the hood, which is given on the

silver label stuck inside the hood. Ensure that the electric system is correctly earthed and that the earth

discharge works correctly.

When cooking do not use any materials that could form high or unusual flames. Oil that has been used

twice and fats are very dangerous and could easily catch fire. Do not prepare flambè dishes under the

hood.

Once the specialized technician has completed the installation of the hood equipped with a remote motor,

all the leads, connectors, ground connections and the remote motor must not be accessible to the user.

Only the installer is granted access by removing the screwed on panels.

Respect local legislation and regulations issued by the relative authorities regarding the exhaust air when

the suction is operating.

Failure to respect and perform all the maintenance and cleaning operations described in this handbook

could cause a fire hazard.

ATTENTION: Accessible parts may become hot when the hood is used with cooking appliances

INSTALLATION

The minimum safety distance between the bottom of the hood and the top of the cooking hob must be 65 cm., smaller

distances must be previously authorised by the manufacturer. (see installation drawings)

The hood can be used for both filtering and suction.

When the filtering function is operating, i.e. with air recycle, carbon filters must be used (refer to the paragraph on

CARBON FILTERS).

When the suction function is operating, i.e. exhausting the filtered air on the outside, a suitable compensation system

must be used according to current standards in force. The diameter of the fume exhaust pipe must be the same or

greater than the diameter of the hood pipe union.

There must be sufficient ventilation in the room where the hood is installed, to allow the simultaneous use of other
