Aqua Mini Full DC Inverter Unitary Chiller 50Hz
23
MGRH12A-PA3Z
Cooling
Chilled
water
outlet
temp.
Ambient temp.(℃)
21.00 25.00 30.00 35.00 40.00 46.00
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
Capacity
Power
EER
(℃)
kW kW W/W kW kW
W/
W
kW kW W/W kW kW W/W kW kW W/W kW kW W/W
5.00 12.54 2.98 4.21 11.81 3.07 3.85 11.14 3.16 3.52 10.53 3.26 3.23 9.86 3.42 2.88 9.08 3.60 2.52
6.00 12.96 3.02 4.29 12.19 3.12 3.91 11.49 3.21 3.58 10.85 3.31 3.28 10.18 3.48 2.93 9.38 3.65 2.57
7.00 13.41 3.08 4.35 12.61 3.18 3.96 11.87 3.28 3.62 11.20 3.38 3.31 10.52 3.55 2.96 9.70 3.73 2.60
8.00 13.83 3.18 4.35 12.99 3.28 3.96 12.22 3.38 3.62 11.51 3.48 3.31 10.82 3.66 2.96 9.99 3.84 2.60
9.00 14.22 3.21 4.43 13.34 3.31 4.03 12.54 3.41 3.68 11.80 3.52 3.36 11.11 3.69 3.01 10.26 3.88 2.65
10.00 14.76 3.26 4.53 13.83 3.36 4.12 12.99 3.46 3.75 12.22 3.57 3.42 11.51 3.75 3.07 10.65 3.93 2.71
11.00 15.17 3.29 4.61 14.20 3.39 4.19 13.32 3.49 3.81 12.52 3.60 3.48 11.81 3.78 3.12 10.94 3.97 2.75
12.00 15.52 3.34 4.65 14.52 3.44 4.22 13.60 3.55 3.84 12.77 3.66 3.49 12.06 3.84 3.14 11.18 4.03 2.77
13.00 15.79 3.36 4.70 14.76 3.47 4.26 13.82 3.57 3.87 12.97 3.69 3.52 12.25 3.87 3.17 11.37 4.06 2.80
14.00 16.19 3.39 4.78 15.11 3.49 4.33 14.14 3.60 3.93 13.25 3.71 3.57 12.54 3.90 3.22 11.65 4.09 2.85
15.00 16.39 3.40 4.82 15.29 3.51 4.36 14.29 3.62 3.95 13.38 3.73 3.59 12.67 3.92 3.24 11.79 4.11 2.87
16.00 16.80 3.44 4.89 15.66 3.54 4.42 14.62 3.65 4.00 13.68 3.77 3.63 12.97 3.95 3.28 12.07 4.15 2.91
17.00 17.02 3.45 4.93 15.85 3.56 4.45 14.78 3.67 4.03 13.81 3.78 3.65 13.11 3.97 3.30 12.22 4.17 2.93
Note: The inlet/outlet water temperature difference is 5°C.
Heating
Note: The inlet/outlet
water temperature difference is 5°C.
Hot
water
outlet
temp.
Ambient temp.(℃)
-10 -6 -2 2 7 10 13
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
Capacity
Power
COP
(℃) kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W kW kW W/W
40.00 7.63 2.33 3.28 9.54 2.65 3.61 11.22 2.94 3.82 12.47 3.19 3.90 13.55 3.36 4.03 15.18 3.56 4.26 17.46 3.85 4.53
41.00 7.39 2.38 3.11 9.25 2.70 3.43 10.89 3.00 3.63 12.12 3.26 3.72 13.18 3.43 3.84 14.74 3.64 4.05 16.92 3.93 4.31
42.00 7.17 2.42 2.96 8.99 2.75 3.26 10.60 3.06 3.46 11.81 3.33 3.55 12.86 3.50 3.67 14.35 3.71 3.87 16.45 4.01 4.10
43.00 7.00 2.47 2.83 8.78 2.81 3.13 10.37 3.12 3.32 11.56 3.39 3.41 12.61 3.57 3.53 14.05 3.79 3.71 16.07 4.09 3.93
44.00 6.87 2.52 2.72 8.63 2.87 3.01 10.20 3.19 3.20 11.38 3.46 3.29 12.42 3.65 3.41 13.81 3.86 3.57 15.78 4.17 3.78
45.00 6.77 2.58 2.63 8.51 2.93 2.91 10.07 3.25 3.10 11.25 3.53 3.18 12.30 3.72 3.31 13.65 3.94 3.46 15.56 4.26 3.65
46.00 6.63 2.60 2.55 8.36 2.96 2.83 9.90 3.28 3.01 11.07 3.57 3.10 12.12 3.76 3.22 13.42 3.98 3.37 15.28 4.30 3.55
47.00 6.44 2.65 2.43 8.12 3.01 2.69 9.63 3.35 2.88 10.78 3.64 2.96 11.81 3.83 3.08 13.06 4.06 3.22 14.84 4.39 3.38
48.00 6.18 2.73 2.26 7.81 3.10 2.51 9.27 3.45 2.69 10.40 3.75 2.77 11.40 3.95 2.89 12.58 4.18 3.01 14.27 4.52 3.16
49.00 5.85 2.84 2.06 7.39 3.23 2.29 8.79 3.59 2.45 9.87 3.90 2.53 10.83 4.11 2.64 11.93 4.35 2.74 13.51 4.70 2.87
50.00 5.47 2.98 1.83 6.93 3.39 2.04 8.24 3.77 2.19 9.26 4.09 2.26 10.18 4.31 2.36 11.20 4.57 2.45 12.65 4.93 2.56
