Aqua Mini Full DC Inverter Unitary Chiller 50Hz
95
Appendix
Accessories
Item Name of accessory Qty Shape
1
Installation and
operation manual
1
2 Rubber sealed ring 2
3 Outlet connection pipe 1
4 Straight screwdriver 1 -----
