Aqua Mini Full DC Inverter Unitary Chiller 50Hz
35
No. Part Name Quantity No. Part Name Quantity
1 Right-front plate ass'y 1 21
Gas-liquid separator
1
2 Four-way valve parts 1 22
Differential pressure switch
1
2.1 Four-way valve ass'y 1 23
Hydraulic meter
1
2.2 Pressure switch 1 24
Display box ass'y
1
3 Welded parts of base 1 25
Outdoor electrical control box ass'y
1
4 Suction pipe ass'y 1 25.1
Module board ass'y
1
4.1 Pressure controller 1 25.2
Radiator
1
5 Accumulator ass'y 1 25.3
Terminal block, 3P
2
6 Fixed plate ass'y of compressor 1 25.4
Radiator
1
7 Compressor 1 25.5
Three phase bridge
1
8 EXV ass'y 1 25.6
Transformer
1
8.1 Electronic expansion valve 1 25.7
Electrolytic capacitor
2
8.2 Expansion valve wire(CAM-MD12GRSZ-5) 1 25.8
Wire joints,12P
1
9 Exhaust valve ass'y 1 25.9
Outdoor control board ass'y
1
9.1 Exhaust valve 1 26
Right back plate
1
10 Connection pipe ass'y 1 27
Inductance Box Ass'y
1
11 Base 1 27.1
PFC Inductor
2
12 Fixed plate of inlet/outlet pipe 1 28
Condenser ass'y
1
13 Connection pipe parts of water pump 1 29
Coaming ass'y
1
13.1 Water charge valve 1 30
Bracket ass'y, net
1
13.2 Safety valve 1 31
Installation plate of expansion tank
1
14 Drain pipe adapter 2 32
Top cover ass'y
1
15 Water pump 1 33
Expansion vessel
1
16 Coaming I 1 34
Rear-left supporting board
1
17 Plate heat exchanger ass'y 1 35
Motor bracket assembly
1
17.1 Electrical heater of plate heat exchanger 1 36
DC Motor
2
17.2 Plate heat exchanger 1 37
Axial fan
2
18 Rubber gasket 1 38
Front Panel
1
19 Coaming II 1 39
Net
2
20 Connection pipe ass'y of differential pressure valve 1 40
Handle
3
20.1 Electrical heater of differential pressure valve 1
25.1
25.2
25.3
25.6
25.7
25.4 25.5
25.9
25.
8
