Soundcraft MSB-32 Cat5 Mini Stagebox 32 (3U) [15/20] Mini stagebox typical specifications

Soundcraft Mini Stagebox 32 User/Installation Guide 0514 15

MINI STAGEBOX TYPICAL SPECIFICATIONS

Frequency Response

Mic / Line Input to any Output: +0/-1dB, 20Hz – 20kHz

T.H.D.

Mic Sensitivity -30dBu: < 0.01% @ 1kHz

Noise

Residual noise: -85dBu

Mic Input E.I.N. (maximum gain): -125dBu (150Ω source)

Mix noise, masters at unity: < -86dBu

1 input to mix at unity gain: -84dBu

CMRR mic @1KHz (max gain): -86dBu

Crosstalk (@ 1kHz)

Mic – Mic: <-80dB @ 1kHz

Input Gain

Mic Gain: -5dB – 58dB integrated pad design 1dB steps

Max. input level: +24dBu

Max. output level: +22dBu

Sample rate: 48kHz

Convertor resolution: 24 bit

Latency: 1.5ms

Internal clock accuracy: +/- 25ppm

Mains power consumption: 33W

Mains voltage operating range: 90 — 264 VAC, 47 — 63Hz

Operating temperature range: -10

C — +50

Relative humidity: 0 — 90%

Storage temperature range: -10

C — +50
