Soundcraft MSB-32 Cat5 Mini Stagebox 32 (3U) [5/20] Important safety warnings

Soundcraft Mini Stagebox 32 User/Installation Guide 0514 5

IMPORTANT SAFETY WARNINGS

THIS APPARATUS MUST BE EARTHED. Under no circumstances should the safety

earth be disconnected from the mains lead.

The mains supply disconnect device is the mains plug. It must remain accessible so as

to be readily operable when the apparatus is in use.

If any part of the mains cord set is damaged, the complete cord set should be

replaced. The following information is for reference only.

The wires in the mains lead are coloured in accordance with the following code:

Earth (Ground): Green and Yellow (US - Green/Yellow)

Neutral: Blue (US - White)

Live (Hot): Brown (US - Black)

As the colours of the wires in the mains lead may not correspond with the coloured

markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured Green and Yellow must be connected to the terminal

in the plug which is marked with the letter E or by the earth symbol.

The wire which is coloured Blue must be connected to the terminal in the plug

which is marked with the letter N.

The wire which is coloured Brown must be connected to the terminal in the plug

which is marked with the letter L.

Ensure that these colour codes are followed carefully in the event of the plug being

changed.

This unit is capable of operating over a range of mains voltages as marked on the rear panel.

The internal power supply unit contains no user serviceable parts. Refer all servicing

to a qualied service engineer, through the appropriate Soundcraft dealer.
