Roland Aerophone AE-10 [11/22] Select restore in the upper and then press the menu button
![Roland Aerophone AE-10 [11/22] Select restore in the upper and then press the menu button](/views2/2007986/page11/bgb.png)
11
Menu Settings
Menu Value Default Explanation
Restore
– –
Restoring user tones and system settings
Here’s how to restore the user tones and system settings from your computer.
1. Using a USB cable, connect your computer to the USB COMPUTER port (p. 3).
2. Select “
Restore
” in the upper, and then press the [MENU] button.
A conrmation message appears.
3. To execute Restore, press the [
A
] (Y) button.
If you decid
e
to cancel, press the [
C
] (N) button.
When you execute, the screen of the Aerophone indicates “WAIT,” and the RESTORE drive appears in the
screen of your computer.
4. Copy the backed-up AE10_BKUP.SVD le into the RESTORE drive.
5. Eject the RESTORE drive, and disconnect the USB cable.
* Don’t turn o the power while the display indicates “WAIT.”
6. When the display indicates “END,” turn the power o and then on again.
–
FctReset
– –
Returning to the Factory Settings (Factory Reset)
Here’s how to return the Aerophone to its factory-set state.
1. Select “
FctReset
” in the upper, and then press the [MENU] button.
A conrmation message appears.
2. To execute the Factory Reset, press the [
A
] (Y) button.
If you decide to cancel, press the [
C
] (N) button.
–
User Clr
– –
Clearing the user tones
Here’s how to clear the user tones. In Ver 2.00 and later, the factory reset operation (FctReset) only resets the system settings,
and does not clear the user tones.
1. Select “
User Clr
” in the upper, and then press the [MENU] button.
A conrmation message appears.
2. To execute the User Clear, press the [
A
] (Y) button.
If you decid
e
to cancel, press the [
C
] (N) button.
–
Version
– –
Version Information
Displays the version of the unit’s system program.
–
