7
Menu Settings
Menu List
2
: Tone Setting S: System Setting
Menu Value Default Explanation
Volume
0–10 8
Adjusting the Volume
You generally adjust the volume by the strength of your breath when performing, but you can also set the volume in the
menu. This changes the volume of the speaker and the PHONES/OUTPUT jack.
S
M.Tuning
415.3–466.2 (Hz) 440.0
Changing the Master Tuning
Changes the tuning of the Aerophone.
The displayed value is the frequency of the A key. With the factory settings, the Aerophone’s tuning is set to A=440.0 Hz, but
you can change this to some other tuning such as 442.0 Hz.
S
Breath
L3, L2, L1, M, H1,
H2, H3
M
Adjusting the Breath Sensitivity
Species how the sound responds to the force of your breath.
L3, L2, L1 Fortissimo () can be produced even by blowing relatively softly.
M This setting is the closest to the response of an actual wind instrument.
H1, H2, H3 Fortissimo () is produced only when you blow quite strongly.
Breath force
Level
M
H1
H2
H3
L1
L2
L3
S
Tone Vol
0–10 10
Tone volume
Species the volume of each tone.
2
Transpos
-5–+6
Depends
on the
tone
Changing the Key (Transpose)
Transposes the pitch range of the tone in semitone steps.
-5 -4 -3 -2 -1 0 +1 +2 +3 +4 +5 +6
If this is set to “0,” the “C” ngering in the “Fingering Chart” at the end of this manual produces the pitch C.
The alto saxophone whose base key is “E
” is set to a transpose setting of “+3,” and the soprano saxophone whose base key is
“B
” is set to “-2.”
2
Octave
-3–+3
Depends
on the
tone
Octave Shift Setting
Shifts the pitch range of the tone in one-octave steps.
The octave shift value is set appropriately for each tone so that it will have the appropriate pitch range. For example, this is set
to “0” for the soprano saxophone, “-1” for the alto saxophone, and “-2” for the baritone saxophone.
2
Reverb
0–10
Depends
on the
tone
Reverb Setting
Adjusts the depth of reverb (the reverberation that is characteristic of a performance in a concert hall).
Higher values produce deeper reverberation; lower values produce shallower reverberation.
2
Chorus
0–10
Depends
on the
tone
Chorus Setting
Adjusts the depth of the chorus eect.
Chorus is an eect that creates a beautiful spaciousness and depth by adding a slightly modulated sound.
2
MFX1
MFX2
Depends on the
tone
Depends
on the
tone
Multi-Eect Setting
Species the depth of the eect that’s assigned to each tone.
* The eect type is set for each tone; it cannot be selected on the Aerophone.
&
For details on the eect signal ow, refer to “Eect Flow” at the end of this manual.
Multi-Eect List
MFX TYPE Display
EQUALIZER EQ
LOW BOOST LOW
ENHANCER EH
AUTO WAH WAH
HUMANIZER HMN
PHASER PH
RING MUDULATOR RNG
TREMOLO TRM
AUTO PAN PAN
ROTARY RTR
FLANGER FL
SPACE-D SPC
MFX TYPE Display
OVERDRIVE OD
DISTORTION DS
COMPRESSOR CMP
LIMITER LM
GATE GAT
DELAY DLY
LONG DELAY LDL
3TAP PAN DELAY 3DL
TELEPHONE TEL
PITCH SHIFTER PS
GATED REVERB GRV
2
