User's Guide HDSP System HDSP 9652 © RME

12.2 DVD-Playback (AC-3/DTS)

AC-3 / DTS

When using popular DVD software players like WinDVD and PowerDVD, their audio data

stream can be sent to any AC-3/DTS capable receiver via the 9652’s AES and SPDIF output.

For this to work an output wave device has to be selected in >Control Panel/ Sounds and Mul-

timedia/ Audio< or >Control Panel/ Sound/Playback<. Also check 'use preferred device only'.

The DVD software's audio properties now show the options 'SPDIF Out' or similar. When select-

ing these, the software will transfer the non-decoded digital multichannel data stream to the

HDSP 9652.

Note

: This 'SPDIF' signal sounds like chopped noise at highest level. The first 2 channels

(Loudspeaker) do not support digital AC-3/DTS playback.

Multichannel

PowerDVD and WinDVD can also operate as software decoder, sending a DVD's multichannel

data stream directly to the outputs of the HDSP 9652. Supported are all modes, from 2 to 8

channels, at 16 bit resolution and 48 kHz sample rate.

For this to work select the WDM playback device ’Loudspeaker’ of the HDSP 9652 in

XP: >Control Panel/ Sounds and Multimedia/ Audio<, and 'Use only default devices' has to be

checked. Additionally the loudspeaker setup, found under >Volume/ Speaker Settings/ Ad-

vanced< has to be changed from Stereo to 5.1 Surround.

Vista/7: >Control Panel/ Sound/ Playback < as ‘Standard’. Additionally the loudspeaker setup,

found under >Configuration<, has to be changed from Stereo to 5.1 Surround.

PowerDVD's and WinDVD's audio properties now list several multichannel modes. If one of

these is selected, the software sends the decoded analog multichannel data to the HDSP 9652.

TotalMix can then be used to play back via any desired output channels.

The typical channel assignment for surround playback is:

1 (first chosen playback channel) - Left

2 - Right

3 - Center

4 - LFE (Low Frequency Effects)

5 - SL (Surround Left)

6 - SR (Surround Right)

Note 1

: Setting the card to be used as system playback device is against common sense, as

professional cards are not specialized to play back system sounds, and shouldn't be disturbed

by system events. To prevent this, be sure to re-assign this setting after usage, or to disable

any system sounds (tab Sounds, scheme 'No audio').

Note 2

: The DVD player will be synced backwards from the HDSP card. This means when us-

ing AutoSync and/or word clock, the playback speed and pitch follows the incoming clock sig-

nal.
