User's Guide HDSP System HDSP 9652 © RME
The ADAT timecode is not in sync
• The tape is formatted to 48 kHz, but played back at 44.1 kHz (Pitch). This 'Blackface' prob-
lem cannot be solved in a satisfactory way.
17.2 Installation
HDSP 9652 is found in the Device Manager (>Settings/ Control Panel/ System<), category
'Sound-, Video- and Gamecontroller'. A double click on 'HDSP 9652' starts the properties dia-
log. Choosing 'Resources' shows interrupt and memory range.
The newest information on hardware problems can always be found on our website www.rme-
audio.com, section FAQ, Hardware Alert: about incompatible hardware.
The dialog 'New hardware component found’ does not appear:
• Check whether the PCI card is completely inserted into the PCI slot.
The card and drivers have been installed correctly, but playback does not work:
• Check whether the Hammerfall DSP appears in the Device Manager. If the ' Hammerfall
DSP’ device has a yellow exclamation mark, then there is an address or interrupt conflict.
• Even if there is no yellow exclamation mark, it's still worth checking the ‘Resources’ tab.
