User's Guide HDSP System HDSP 9652 © RME

Mouse: The original factory presets can be reloaded by holding down the Ctrl-key and clicking

on any preset button. Alternatively the files described above can be renamed, moved to a dif-

ferent directory, or being deleted.

Keyboard: Using Ctrl and any number between 1 and 8 (not on the numeric

keypad) will load the corresponding factory default preset. The key Alt will

load the user presets instead.

When loading a preset file, for example 'Main Monitor AN 1_2 plus

headphone mix 3_4.mix', the file name will be displayed in the title bar of the

TotalMix window. Also when loading a preset by the preset buttons the name

of the preset is displayed in the title bar. This way it is always clear what the

current TotalMix state is based on.

The eight factory presets offer a pretty good base to modify them to your personal needs. In all

factory presets Submix View is active by default.

Preset 1

Description: All channels routed 1:1, monitoring of all playback channels.

Details: All inputs maximum attenuation. All playback channels 0 dB, routed to the same output.

All outputs 0 dB. Level display set to RMS +3 dB. View Submix active.

Note

: This preset is Default, offering the standard functionality of a I/O-card.

Preset 2

Same as Preset 1.

Preset 3

Description: All channels routed 1:1, input and playback monitoring via outputs. As Preset 1, but

all inputs set to 0 dB (1:1 pass through).

Preset 4

Description: All channels routed 1:1, input and playback monitoring via outputs. As Preset 3, but

all inputs muted.

Preset 5

Description: All faders maximum attenuation. As Preset 1, but all playbacks maximum attenua-

tion.

Preset 6

Description: Submix on SPDIF at -6 dB. As Preset 1, plus submix of all playbacks on SPDIF.

Preset 7

Description: Submix on SPDIF at -6 dB. As Preset 1, plus submix of all inputs and playbacks on

SPDIF.

Preset 8

Description: Panic. As Preset 4, but playback channels muted too (no output signal).

Preset Banks

Instead of a single preset, all eight presets can be stored and loaded at once. This is done via

Menu File, Save All Presets as and Open All Presets (file suffix .mpr). After the loading the

presets can be activated by the preset buttons. In case the presets have been renamed (see

chapter 26.11), these names will be stored and loaded too.
