MIDI CONTROL CHANGE (CC) MESSAGES
The tables on the following pages list all MIDI CC messages for the
Sirin. Messages shown with an (M) indicate parameters which are
only accessible via MIDI. Bolded values indicate the appropriate range
for 7-bit messages (MSB).
NOTES:
• Sirin sends 7-bit MIDI CC messages for all parameters. It
can receive either 7-bit or 14-bit values for the parameters
controlled by knobs, but only 7-bit values for parameters con-
trolled by switches.
• For all parameters, the MSB indicates the ‘regular’ CC number,
and the LSB indicates the high-resolution ‘fine’ control value.
If you are only sending 7-bit MIDI CC messages to the Sirin,
use the MSB number by itself. Note that when MSB-only
messages are issued, the value range is always 0-127.
A NOTE ABOUT CONTROL PARAMETERS
LOCAL CONTROL OFF (CC# 122):
This parameter allows the front panel controls to send MIDI, but disconnects
the Sirin sound engine from direct control by the panel. Per the MIDI
spec, only values of ‘0’ and ‘127’ work (0 = OFF, 127 = ON). If you are conn-
ected to a DAW using USB MIDI patched through, you may need this to
avoid feedback artifacts. After changing the state of LOCAL CONTROL
on/off, the Sirin remembers the last setting after power down.
ALL SOUNDS OFF/ALL NOTES OFF (CC 120 or 123):
Both of these parameters are MIDI ‘panic’ functions that are used to silence
hung MIDI notes. Controllers or DAWs may send one or the other command
which is why the Sirin will respond to either.
21
SECTION
MOD(MODULATION)OSCILLATORSMIXERFILTER
FUNCTION CC VALUE/RANGE
CONTROL/
PARAMETER
LFO RATE Adjusts the LFO frequency
3(MSB)
35(LSB)
0-127
0-127
0-127
0-63(INT)
64-127(MIDI CLOCK)
See table on
page 24
0-63(OFF)
64-127(ON)
0-63(SAW)
64-127(SQR)
0-63(SAW)
64-127(SQR)
0-63(OFF)
64-127(ON)
0-63(OFF)
64-127(ON)
0-42(LCR)
43-84(LCT)
85-127(EXP)
0-63(Always Glide)
64-127(Glide on
legato notes only)
0-127
(64 is center)
0-127
0-127
0-127
0-127
0-127
0-127
0-127
0-127
0-127
0-127
13(MSB)
45(LSB)
12(MSB)
44(LSB)
87
86
82
70
71
17(MSB)
49(LSB)
18(MSB)
50(LSB)
15(MSB)
47(LSB)
16(MSB)
48(LSB)
27(MSB)
59(LSB)
19(MSB)
51(LSB)
21(MSB)
53(LSB)
22(MSB)
50(LSB)
20(MSB)
54(LSB)
89
81
65
92
83
5(MSB)
LFO VCO AMOUNT Adjusts the modulation amount
to the VCOs
LFO VCF AMOUNT Adjusts the Modulation amount
to the VCF
LFO MIDI SYNC
(M)
LFO SYNC CLOCK
DIV (M)
Sets the LFO synchronization
clock divider
Enables or disables ability of LFO
to sync with MIDI CLOCK messages
LFO KEY TRIGGER
(M)
VCO 1 WAVE Selects the waveform of VCO 1
Selects the waveform of VCO 2
Adjusts the frequency of VCO 2
Adjusts the beat frequency of
VCO 2 (Default is 64)
Enables/disables Note Sync
(Default is off)
Adjusts the Glide (portamento)
rate time
22
Sets the state of the GLIDE switch
(Glide is enabled when LED is lit)
Selects the type of Glide; Linear
Constant Rate, Linear Constant Time,
or Exponential.
Sets the state of the Legato Glide
parameter when GLIDE is enabled
(Default is OFF)
VCO 2 WAVE
VCO 2 FREQ
VCO 2 BEAT
(M)
GLIDE RATE
NOTE SYNC
(M)
GLIDE SWITCH
GLIDE TYPE
(M)
LEGATO GLIDE
(M)
VCO 1
CUTOFF Adjusts the Filter Cutoff frequency
RESONANCE Adjusts the Filter Resonance
parameter
EG AMOUNT Adjusts the EG amount affecting
the cutoff
FILTER KB TRACK
(M)
Sets the amount of keyboard tracking
for the filter (Default is 32 - about 50%)
FILTER VELOCITY
SENSITIVITY (M)
Sets the amount of filter velocity
sensitivity (Default is 64 - 50%)
Adjusts the level of VCO 1
VCO 2 Adjusts the level of VC0 2
EXTERNAL IN
LEVEL (M)
Adjusts the level of the External Audio
Input (Default is 64 = 50% level)
Re-triggers the LFO to the start of
the cycle (Default is OFF)
