APPENDIX C - CARING FOR THE SIRIN
Clean the Sirin with a soft, slightly moist cloth only – do not use solvents
or abrasive detergents. Heed the safety warnings at the beginning of the
manual. Don’t drop the unit. If you are shipping your Sirin to the factory
for servicing, we recommend using the original shipping carton, or an ATA
approved Road Case.
AN IMPORTANT NOTE ABOUT SAFETY: Do not open the chassis. There are
no user serviceable parts in the Sirin. Maintenance of the Sirin
synthesizer should be referred to qualified service personnel only.
APPENDIX D - SPECIFICATIONS
TYPE: Programmable Monophonic
Analog Bass Synthesizer
SYNTH ENGINE:
Oscillator Section:
•OSCILLATOR 1:
Wave: Sawtooth/Square
Level: 0 to 100%
•OSCILLATOR 2:
Frequency: +/-12 Semitones
Wave: Sawtooth/Square
Level: 0 to 100%
•GLIDE RATE: 0 to 100%
Filter Section:
•CUTOFF: 20Hz to 20KHz
•RESONANCE: 0 to Self-Oscillation
•FILTER ENV. AMOUNT: -100% TO +100%
Envelope Generator Section (x2):
•ATTACK TIME: 1 msec to 30 sec
•DECAY TIME: 1 msec to 30 sec
•SUSTAIN LEVEL: 0 to 100%
•RELEASE TIME: 1 msec to 30 sec
•RELEASE: On/Off
Modulation Section:
•LFO RATE WITH RATE LED: 0.01 to 100Hz
•WAVE: Triangle
•AMOUNT TO VCO: 0 to 100%
•AMOUNT TO VCF: 0 to 100%
27
APPENDIX D - SPECIFICATIONS
PERFORMANCE CONTROLS:
•FINE TUNE: +/- 1 Semitone
•GLIDE: On/Off
•RELEASE: On/Off
•MASTER VOLUME
REAR PANEL:
•12VDC POWER INLET:
Accepts +12VDC, tip positive
•MONOPHONIC AUDIO IN (1/4” TS-UNBALANCED)
Accepts +4dBu line level signal
•MONOPHONIC AUDIO OUT (1/4“ TS-UNBALANCED)
•HEADPHONE JACK (1/8” TRS STEREO MINIJACK)
•CONTROL VOLTAGE INPUTS:
Pitch CV: 0 to +5V
Filter CV: 0 to +5V
Volume CV: 0 to +5V
Gate: +5V trigger
•DIN MIDI: MIDI Input
•USB MIDI: MIDI input, MIDI Output
DIMENSIONS:
•8.75” x 5.12” x 3.12”
•(222.3mm x 130.2mm x 79.4mm)
WEIGHT:
•2.5 lb
•(1.2 kg)
OPERATING SYSTEM:
•FLASH UPGRADEABLE VIA MIDI SYSEX
POWER CONSUMPTION:
• 7 WATTS
*Specifications subject to change without notice
©2018 MOOG MUSIC INC. | 160 Broadway St. Asheville, NC 28801
Moog is a registered trademark of Moog Music Inc.
The Moog Wordmark is a registered trademark of Moog Music Inc.
The Moog Icon is a registered trademark of Moog Music Inc.
Sirin is a trademark of Moog Music Inc.
WWW.MOOGMUSIC.COM
28
