APPENDIX A - MIDI IMPLEMENTATION CHART
FUNCTION TRANSMITTED RECOGNIZED REMARKS
BASIC CHANNEL
Default 1 1
Changed 1-16 1-16 User Selectable
VELOCITY
Note On NO YES
Note Off NO NO
SYSTEM REAL TIME
Clock NO YES Receives Timing Clock
Commands NO YES
AUX MESSAGES
Local Off NO YES
All Notes Off NO YES
Active Sense NO NO
System Reset NO NO
25
SYSTEM COMMANDS
Song Position NO NO
Song Selection NO NO
Tune NO NO
MODE
Default NO 4 Note Priority
Messages NO NO MIDI CC# 91
Altered NO NO
NOTE NUMBER NO 0-127
AFTER TOUCH NO NO
PROGRAM CHANGE NO NO
SYSTEM EXCLUSIVE YES YES
PITCH BEND NO YES Programmable from
0 ± 24 Semitones
CONTROL CHANGE YES YES 1,3,5,7,12,13,15-25,
27-30,33,35,37,39,
44,45,47-57,59-62,
65,70-73,81-83,86,
87,89-92,107,108,
120,122,123
APPENDIX B - SERVICE AND SUPPORT
INFORMATION
26
MOOG’S STANDARD WARRANTY
Moog warrants its products to be free of defects in materials or workmanship and
conforming to specifications at the time of shipment. The Warranty Period is one
year from the date of purchase. If, in Moog’s determination, it has been more than
five years since the product shipped from our factory, it will be at Moog’s discre-
tion whether or not to honor the warranty without regard to the date of the
purchase. During the Warranty Period, any defective products will be repaired or
replaced, at Moog’s option, on a return-to-factory basis. This warranty covers
defects that Moog determines are no fault of the user.
The Moog Limited Warranty applies to USA purchasers only. Outside the USA the
warranty policy and associated service is determined by the laws of the country of
purchase and supported by our local authorized distributor. A listing of our
authorized distributors is available on moogmusic.com.
If you purchase outside of your country, you can expect to be charged for
warranty as well as non-warranty service by the service center in your country.
RETURNING YOUR PRODUCT TO MOOG MUSIC
You must obtain prior approval in the form of an RMA (Return Material Authoriza-
tion) number from Moog before returning any product. Email techsupport@moog-
music.com for the RMA # via email or call us at (828) 251-0090. All products must
be packed carefully and shipped with the Moog supplied power adapter. The
Moog Sirin must be returned in the original inner packing including the cardboard
inserts. Sorry, the warranty will not be honored if the product is not properly
packed. Once you have received the RMA# and carefully packed your Moog, ship
the product to Moog Music Inc. with transportation and insurance charges paid,
and include your return shipping address.
MOOG MUSIC
160 Broadway St.
Asheville NC, 28801
WHAT WE WILL DO
Once received, we will examine the product for any obvious signs of user abuse or
damage as a result of transport. If the product abused, damaged in transit, or is
out of warranty, we will contact you with an estimate of the repair cost. Warranty
work will be performed and Moog will ship and insure your product to your United
States address free of charge.
HOW TO INITIATE YOUR WARRANTY
Please initiate your warranty online at www.moogmusic.com/register. If you do
not have web access, please call (828) 251-0090 to register your product.
