POWER UP
Apply power to the Sirin and to your MIDI controller.
CONNECT TO AMPLIFIER
Set Sirin’s volume control to minimum before connecting to an amplifier,
mixer, or headphones. Set the amplifier volume to a comfortable listening
level, and then slowly bring up the volume on Sirin as you play a few notes.
NOTE: Use caution when adjusting initial volume levels, especially if connected
to a subwoofer.
START PLAYING
Play some notes, tweak some knobs and have some fun!
DOWNLOAD THE MINI
TAUR EDITOR PROGRAM
Register your Sirin online at www.moogmusic.com/register to download
the free Sirin Editor Program. This allows you to load and save patches
and access all of Sirin’s under the hood features. Registering your
Sirin also initiates your warranty, and ensures you receive the latest
software updates.
NOTE: A warm up period of about 15 minutes is recommended for
reach concert pitch. The warm up period may be a little longer if the Sirin has
been stored outside the recommended operating temperatu
re range.
Sirin’s recommended operating temperature is between 50 and 100 degrees
Farenheit. It is safe to operate the synthesizer outside of this range, but Sirin’s
voltage controlled oscillators may not remain in tune. It is also recommended that
Sirin not be exposed to direct sunlight while operating.
5
OVERVIEW AND FEATURES
Sirin is a monophonic Analog Synthesizer with a 100% analog audio
path. It is based on the legendary Taurus I and Taurus 3 Synthesizers. Sirin
features 2 ultra-stable voltage controlled oscillators, a genuine Moog low pass
filter, 2 envelope generators and a modulation circuit. Sirin has a classic
one knob per function design in a rugged performance package that is small
enough to take with you anywhere.
OSCILLATORS
Two Voltage Controlled Oscillators with selectable Sawtooth (original
Taurus) and Square waveshapes.
MIX
Mixer for adjusting VCO levels independently.
FILTER
Classic Moog 24dB/Octave Low Pass Filter with adjustable Resonance.
ENVELOPES
Twin Minimoog style ADSR Envelope Generators for modulating the
Filter (VCF) and Amplifier (VCA). The Envelope Decay and Release
segments are controlled by the DECAY knob, while the Release
segmentis enabled or disabled via the RELEASE switch.
MOD
MIDI-syncable Low Frequency Oscillator (LFO) with Rate control and
and individual VCO and VCF AMOUNT controls.
6
FRONT PANEL
