LA4X_UM_EN_2.0 w w w . l - a c o u s t i c s . c o m 31

Figure 26: Loading a preset (example with a factory preset)

Complements about the LOAD PRESET screen

The upper line of the screen displays the preset family allowing coarse selection while the bottom line displays

the preset name allowing preset selection within a family.

If the name of the displayed preset has been modified (user presets only), it is possible to display the original

name pressing and holding the encoder wheel.

4.5 STORE PRESET

The current preset and the possible setting modifications can be stored to a user memory (1-10).

Modifications flag

The modifications of the preset parameters are indicated by a star sign (on the top right corner of the LCD

screen) until the preset has been stored to a user memory or set to its initial settings.

There is a risk of loosing the preset parameter modifications

Preset parameter modifications (see section 4.7) are not automatically saved to the current preset: they will be

lost if the preset is reloaded prior to storing it (e.g. while the star sign is displayed). However, the current state

is saved when the controller is shut down.

To store a preset follow these steps (see also Figure 27):

From the main menu select STORE PRESET. 1.

Turn the encoder wheel to scroll through the user memories. 2.

Press the OK key or the encoder wheel to select a user memory (or ESC to abort). 3.

If the controller displays OVERWRITE? it means that a preset is already stored in the selected user memory. 4.

Press the OK key or the encoder wheel to validate (or ESC to abort).

If necessary enter a new preset name (16 characters max) as follows: 5.

a. Turn the encoder wheel to select the first character.

b. Press the encoder wheel to go to the next character.

c. Repeat these steps until the new name has been entered.

Pressing the encoder wheel from the 16

character makes the cursor return to the first character so

that it is possible to apply the procedure a new time for possible corrections.

Press the OK key to validate (or ESC to abort). 6.

The preset is stored and the main screen is displayed.
