4.10 MONITORING AND INFO

This menu provides real-time measurements to monitor the output channels and provides the versions of embedded

software. In more details, the MONITORING AND INFO menu allows to:

 Display in real-time the RMS output voltage and output temperature for each output channel.

The output voltage is given in percentage of the maximum value supported by the particular transducer section

connected. The temperature is given in percentage of the operating range.

 Display the firmware and factory preset library versions.

 Display the controller’s MAC address.

Figure 38 shows all pages of the MONITORING AND INFO menu. Each one is detailed in sections from 4.10.1 to

4.10.5.

Figure 38: MONITORING AND INFO menu pages
